Solar Photovoltaic Grid-Connected Key Technology

Abstract:

In order to solve the problem of solar energy photovoltaic grid technology, a kind of photovoltaic grid-connected simulation device based on FPGA was designed. It consists of FPGA, auxiliary fly-back switch power, full-bridge DC/AC converter, LC filter and some protecting circuit etc. The device has high speed of MPPT adjustment and tracking of frequency and phase, with frequency ranging from 30Hz to 55Hz, deviation is below 0.4%, stability is above 99.6%, converting efficiency is up to about 80%.

• Periodical: Applied Mechanics and Materials (Volumes 291-294)
• Pages: 2028-2031
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.291-294.2028
• Online since: February 2013
• Authors: Feng Wen
• Keywords: Field-Programmable Gate Array (FPGA), Grid Connected, MPPT, Solar Photovoltaics, SPWM

References

[1] Trong S J. World overview of building-integrated photovoltaic[C]. Conference Record of the Twenty Fifth IEEE. Washington, DC. IEEE, 1996, pp.1197-1202.

DOI: 10.1109/pvsc.1996.564346

[2] Solodovnik E V, Dougal R A. Power controller design for maximum power tracking in solar installations. IEEE Transaction on Power Electronics, 2004, 19(5): 1295-1304.

DOI: 10.1109/tpel.2004.833457

[3] Song Qing, Liu Wen-hua, Yan Ping-Gui. LC filter design for high power PWM voltage source inverter[J]. Journal of Tsinghua University: Science and Technology, 2003, 43(3): 345-348.

[4] Yu Yang-wei, Jin Tian-jun, Xie Wen-tao, Lv Zheng-yu. LC filter based on PWM inverter[J]. Mechanical & Electronical Engineering Magazine, 2007, 24(5): 50-52.
