DSP - Based Islanding Protection for Photovoltaic Grid Connected Inverter

Abstract:

This research presents the DSP - based islanding protection for photovoltaic grid connected inverter with under / over frequency and under / over voltage islanding protection methods. The design is based on the TMS320VC33PGE digital signal processor on the NI SPEEDY 33 board from National Instrument Inc. The prototype is monitor the grid frequency and grid voltage at the point of common coupling (PCC) between the photovoltaic grid connected inverter, the local load and the distribution. The results of study, the prototype can turn off relay between photovoltaic grid connected inverter and utility grid when the frequency is change under 48Hz or over 52Hz and the voltage is change under 200V or over 240V.

• Periodical: Applied Mechanics and Materials (Volumes 291-294)
• Pages: 2007-2010
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.291-294.2007
• Online since: February 2013
• Authors: Khanchai Tunlasakun
• Keywords: Digital Signal Processor (DSP), Grid-Connected Inverter, Islanding, Photovoltaic (PV)

References

[1] Muhammad H. Rashid, Power Electronics Handbook, Academic Press, (2001).

[2] IEA International Energy Agency, Evaluation of Islanding Detection Methods for Photovoltaic Utility Interactive Power systems, Report IEA PVPS T509: (2002).

[3] http: /www. ni. com.

[4] D.C. Martins, R. Demonti and I. Barbi, Usage of the Solar Energy from the Photovoltaic Panels for the Generation of Electrical Energy, INTELEC 99.

DOI: 10.1109/intlec.1999.794089

[5] H. Kobayashi, K. Takigawa, E. Hashimoto Method for Preventing Islanding Phenomenon on Utility Grid with a Number of Small Scale PV Systems, Prc. The 22nd IEEE PVSC, pp.695-700.

DOI: 10.1109/pvsc.1991.169299
