The Optimization Design of High Precision Long-Range Cartesian Coordinate Robots’ Drive System

Abstract:

At present, Cartesian Coordinate Robot driving systems have several ways, such as timing-belt, screw, rack-pinion and chain. But, they are difficult to synchronously meet needs of high precision, long range and heavy load. In this paper, Trochoid Cam Gear (TCG) was used as main transmission mechanism to implement high precision and long range motion of the secondary girder of a Cartesian Coordinate Robot, and disposed reasonably the space positions of linear rails and servo motors to meet the needs of heavy load.

• Periodical: Applied Mechanics and Materials (Volume 302)
• Pages: 574-577
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.302.574
• Online since: February 2013
• Authors: Xian Teng Han, Yu Wang, He Ting Tong
• Keywords: Cartesian Coordinate Robot, Linear Guide, Optimization Design, Trochoid Cam Gear

References

[1] Li-hua Zhang, Yan Zheng. New mechanical design manual. People's Posts and Telecommunications Press. (2008).

[2] Yun-na Xue, Yong wang. Method of the TCG and parametric design. Submitted to Journal of Shandong University Research. (2004).

[3] Yun-na Xue, Yong wang, Xian-lun Wang. Theory of cycloid transmission conjugate meshing. 4th, (2005).

[4] Heng Sun, Zuo-mo Chen, Wen-jie Ge. Theory of machines and mechanisms. China Higher Education Press. (2009).

[5] Xue-song Tan, Li-hua Zhang. Applications of Pro/ENGINEER. People's Posts and Telecommunications Press. (2009).

[6] Xian-kui Wang. Technology of mechanical manufacture. China Machine Press. (2010).
