Automatic Block Detection for Ink Jet Head

Abstract:

Inkjet printing technology has been used in several areas and the inkjet printer uses different inks, for example oil ink for cloth printing, color glaze ink for ceramic printing and so on. The printer ink jet head uses these inks are blocked frequently. An automatic block detection system has been presented in this paper. The system provides droplet deposition apparatus comprising of: a fluid chamber; a nozzle in fluid communication with the chamber for ejection of fluid; a monitor; CCD camera; image capturing and processing module. The system has applied to ink jet and droplet image detection and it is proved effective and the detection result is accuracy.

• Periodical: Applied Mechanics and Materials (Volume 310)
• Pages: 424-427
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.310.424
• Online since: February 2013
• Authors: Xiao Jie Xiu, Hong Jun Tang
• Keywords: Block Detection, Image Processing, Ink Droplet, Ink Jet Head

References

[1] Y. Caspi and M. Irani. (2000). A step towards sequence-to-sequence alignment. Pro19th IEEE Conf. on Computer Vision and Pattern Recognition, Hilton Head Island. vol2, 682–689.

DOI: 10.1109/cvpr.2000.854940

[2] L. Wolf and A. Zomet.(2002). Correspondence-free synchronization and reconstruction in a non-rigid scene. Proc. Workshop on Vision and Modelling of Dynamic Scenes,Copenhagen .

[3] Moses, Michael P., Collicott, Steven H., Heister, Stephen D.(1999). Detection of aerodynamic effects in liquid jet breakup and droplet formation. Journal of the International Institutions for Liquid Atomization and Spray Systems. Vol9(4), pp.331-342.

DOI: 10.1615/atomizspr.v9.i4.10

[4] Lu, Ping-Chou, Yeh, Syh-Shiuh.(2008). Paper path detection in ink jet printers by using speed perturbation observer. Proceedings of the 17th World Congress, International Federation of Automatic Control, IFAC.

DOI: 10.3182/20080706-5-kr-1001.01238

[5] Lu Yun-peng, CUI Yu-juan, LI Chao(2010). Design about Ink-jet Head Detector of Printer Based on CPLD. MODERN ELECTRONICS TECHNIQUE. Vol 33(7), pp.172-174.

[6] ZHANG Qiu Feng, LIU Jin(2010). Design and realization of multi-nuzzle printer based on PC platform's control system. MICROCOMPUTER & ITS APPLICATIONS. Vol29(24). P93-95.

[7] Sato, Tsuyoshi; Higuchi, Toshiro(2008). Study on detection technique for jetting failure of piezo-driven inkjet heads. Vol74(7). P740-745.

DOI: 10.2493/jjspe.74.740

[8] Byung-Hun Kim, Sang-Il Kim. etc.(2011). A Study of the Jetting Failure for Self-Detected Piezoelectric Inkjet Printheads. IEEE SENSORS JOURNAL, VOL. 11, NO. 12. P3451-3456.

DOI: 10.1109/jsen.2011.2160979

[9] A. Scardovi.(1987). Ink jet print head. U.S. Patent 465852.

[10] G. Kwon, W. Kim(2007). A waveform design method for high speed piezo inkjet printing based on self-sensing measurement. Sens. Actuator A, Phys.. Vol. P75–83.

DOI: 10.1016/j.sna.2007.06.010
