Research of High Performance Polarization-Independent Grating Beam Splitter

Abstract:

Based on a silicon-on-insulator (Silicon-on-insulator, SOI) material system design and optimization of a high performance, the polarization independent of 1 × 3 subwavelength grating stars beam splitter. By a rigorous coupled-wave analysis method showed that, in the 1550nm wavelength range, at vertical incidence, the device on the transverse electric field (transverse electric, TE) ,the 0 and ± 1 order transmittance is 31%, 32%, 32%,respectively; cross the magnetic field (transverse magnetic, TM), the 0 and ± 1 transmittance is 33%, 32%, 32%, respectively.

• Periodical: Applied Mechanics and Materials (Volume 310)
• Pages: 481-485
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.310.481
• Online since: February 2013
• Authors: Ke Zhao, Xiao Min Lei, Guo Feng Xie, Wen Hua Xiong
• Keywords: Grating Beam Splitter, Polarization-Independent, Rigorous Coupled Wave Analysis, SOI

References

[1] R. Schnabel, A. Bunkowski, O. Burmeister, and K. Danzmann, " Three-port beam splitters–combiners for interferometer applications, " Opt. Lett. 31, 658–660 (2006).

DOI: 10.1364/ol.31.000658

[2] J. Ciosek, J. A. Dobrowolski, G. A. Clarke, and G. Laframboise, "Design and manufacture of all-dielectric nonpolarizing beam splitters," Appl. Opt. 38, 1244–1250 (1999).

DOI: 10.1364/ao.38.001244

[3] C. Guang, S. Jin, L. Yuan, "Photonic crystal polarizing and non-polarizing beam splitters," Chin.Phys.Lett. 25, 556-558 (2008).

DOI: 10.1088/0256-307x/25/2/055

[4] I. Day, I. Evans, A. Knights et al. "Tapered silicon waveguides for low insertion loss highly-efficient high-speed electronic variable optical attenuators," Optical Fiber Communications Conference, 1, 249–251(2003).

DOI: 10.1109/ofc.2003.1247634

[5] J. Feng, C. Zhou, B. Wang, J. Zheng, W. Jia, H. Cao and P. Lv, " Three-port beam splitter of a binary fused-silica grating, " Appl. Opt. 47 , 6638–6643 (2008).

DOI: 10.1364/ao.47.006638

[6] J. Feng, C. Zhou, J. Zheng, H. Cao and P. Lv, "Dual-function beam splitter of a subwavelength fused-silica grating, " Appl. Opt. 48, 2697–2701 (2009).

DOI: 10.1364/ao.48.002697

[7] M. Shokooh-Saremi and R. Magnusson, "New nonpolarizing resonant beam splitters," IEEE Photonics Journal 2, 670–676 (2010).

DOI: 10.1109/jphot.2010.2057502

[8] M. G. Moharam, E. B. Grann, and D. A. Pommet, "Formulation for stable and efficient implementation of the rigorous coupled-wave analysis of binary gratings[J].,"J. Opt. Soc. Am. A, 12,1068-1076 (1995).

DOI: 10.1364/josaa.12.001068

[9] W. Lee and F. L. Degertekin, "Rigorous coupled-wave analysis of multilayered grating structures[J],"J. Lightw. Technol. 22,2359-2363 (2004).

DOI: 10.1109/jlt.2004.833278

[10] W. Lee and F. L. Degertekin, "Rigorous coupled-wave analysis for multilayered grating structures," Proc. of SPIE 4987, 264-273(2003).

[11] Z. Zhou, D, Gao, Y, Wang et al. "Si-based optoelectronic devices for optical communications (Invited)," Proc. of SPIE, 6352, 635221-1-635221-11(2006).
