Study on Optimal Design of Case Ejector Mechanism of Tank Autoloader Based on Kinematical Simulation

Abstract:

To make optimal design of case ejector mechanism easier and more efficiency, a novel method based on kinematical simulation and combining modern computer technology with the features of traditional linkage design is presented. By analyzing transmission state of double-rocker mechanism of ejector, establishing a kinematical simulation model and determining the appropriate data of the mechanism, a designer could easily design a case ejector satisfying all the requirements on movement or trajectory in the given conditions. Meanwhile, the transmission factor of the mechanism is highly increased. The results from optimal design of the case ejector of certain type of tank show that the transmission factor of the mechanism is increased by 58.4%.

• Periodical: Applied Mechanics and Materials (Volume 312)
• Pages: 191-195
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.312.191
• Online since: February 2013
• Authors: Ya Ning Chen
• Keywords: Case Ejector, Kinematical Simulation of Mechanism, Optimization Design of Mechanism

References

[1] Zhang Zhenshan: Introduction of Armored Vehicle Weapon System (Firepower Section) (The Academy of Armored Forces Engineering, Beijing, 2003).

[2] Ma Dejun, Chen Yaning: Design and Analsis on Common Mechanism and Spare Parts of Armored Equipment (Weapon Industry Press, Beijing, 2006).

[3] Zhang Ce: Mechanical Principle and Mechanical Design (China Machine Press, Beijing, 2011).

[4] Cao Weiqing: Analysis and Synthesis on Linkage Mechanism (Science Press, Beijing, 2002).

[5] Chen Lizhou: Mechanical Optimization Design (Shanghai Scientific and Technical Publishers, Shanghai, 1982).
