Calculation Method on the Cooling Roller of Waterless Offset Press

Abstract:

In order to control the temperature of the ink, a cooling roller is used to cool down the temperature of the blanket cylinder. The calculation of the heat transfer on cooling roller is divided into two parts: One part is the exchange heat with the air through the cooling roller and the blanket cylinder, the other part is the heat conduction of the cooling roller and the blanket cylinder on the contact area. The heat conduction on the contact area is divided into the thermal conductivity generated by the friction and the heat conduction from blanket to the cooling roller.

• Periodical: Applied Mechanics and Materials (Volume 312)
• Pages: 196-199
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.312.196
• Online since: February 2013
• Authors: Lin Jin, Yan Li, Xiao Zhang, Miao Liu
• Keywords: Cooling Roller, Friction, Heat, Heat Exchange, Waterless Offset

References

[1] YANG Shi-ming: Heat transfer theory (People's education press, Beijing 1982)

[2] JIN Lin: The temperature control device of the waterless (the thesis of Beijing Institute of Graphic Communication)

[3] Silvestre, Alain, Breuille Vert, FR. Einrichtung zur Temperierung eines Druckwerkzylinders im Druckwerk einer Rotationsdruckmaschine. DE 196 41 031 A1. 12. Juni 1997.

[4] [4]WANG Shuang-cheng, WANG Qian: The calculation of water's physical properties (The journal of Henan TV University, 2000, p.31)

[5] CHENG Hong: Principles and design of the modern printing machinery (China Light Industry Press, Beijing 2007)

[6] Wang Ye-ping: Journal of mechanical Vol. 29 (2002), p.20.
