Simulation of Flow Field and Calculation of Moment on Valve Plate for Butterfly Valve

Abstract:

In order to control the flow rate in a butterfly valve accurately, the moment, which acts on the rotation axis of valve plate, caused by flowing fluid must be considered. Taking air as the medium, the parameters of internal flow fields, such as the velocity and pressure, are simulated by CFD for a standard butterfly valve. The distribution of velocity and pressure fields that changes with various openings and a curve of aerodynamic moment are obtained. The results show that, as the opening of valve goes larger, the resultant moment on valve plate is monotonically increased. At the opening of 70°, the moment reaches its maximum. After the opening of 70° the moment begins monotonically decreasing and the resultant moment is close to zero at 90°.

• Periodical: Applied Mechanics and Materials (Volume 312)
• Pages: 186-190
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.312.186
• Online since: February 2013
• Authors: Xiao Hong Jin, Yang Shen, Qin Fen Miao
• Keywords: Aerodynamic Moment, Flow Field, Simulation

References

[1] Park Youngchul, Soug Xueguan: Numerical analysis of large diameter butterfly valve. Advances in Computational Algorithms and Data Analysis. Vol. 14 (2008), pp.349-363.

DOI: 10.1007/978-1-4020-8919-0_24

[2] Zachary Leutwyler, Charles Dalton: A CFD of study of the flow field, resultant force, and aerodynamic torque on a symmetric disk butterfly valve in a compressible fluid. Journal of Pressure Vessel Technology. Vol. 130(2008), p.021302.1-021302.10.

DOI: 10.1115/1.2891929

[3] Danbon F., Solliec C: Aerodynamic torque of a butterfly valve influence of an elbow on the time-mean and instantaneous aerodynamic torque. Journal of Fluids Engineering. Vol. 122 (2000), pp.337-344.

DOI: 10.1115/1.483262

[4] HE Zhiguo, MAO Genhai: Numerical simulation of 3D turbulence simulation in a cut-off valve and flow characteristics in pipes. Journal of Hydrodynamics, Ser. B. Vol. 15 (2003), pp.86-91.

[5] Lin F., Schohl G: A CFD prediction and validation of butterfly valve hydrodynamic force. Word Water Congress. (2004).

DOI: 10.1061/40737(2004)232

[6] Chen M. J.: Wang C. C. Control of volumetric flow-rate of ball valve using V-port. Journal of Fluid Engineering. Vol. 126 (2004), pp.471-481.

DOI: 10.1115/1.1760536

[7] Fu Xiangzhao, Long Tianyu, and Su Yaxin: Computational Fluid Dynamics (Chongqing University Press, Chongqing 2007).

[8] Jin Xiaohong: Research on the Electro-hydraulic Servo System for the Opening Control of a Large Size Valve. Journal of Wuhan Yejin University of Science and Technology. Vol. 20 (1997), pp.211-212.
