Optimal Design of NW Planetary Gear Reducer

Abstract:

The paper make optimal design of NW planetary gear reducer. While all the design factor has been considered, the optimal mathematical model and constraint conditions of each independent variable is determined. On the basis of simplifying model, the MATLAB is used to develop the algorithm program. Then the program is carried out. Finally, the operational results are revised and checked. The operational results show that this method can ensure the design quality. At the same time, the method also can enhance the efficiency of programming.

• Periodical: Applied Mechanics and Materials (Volume 312)
• Pages: 277-281
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.312.277
• Online since: February 2013
• Authors: Xiang Jun Hui
• Keywords: Fmincon, MATLAB, NW Planetary Reducer, Optimal Design

References

[1] Zhangzhan, zhanghongsong, in: Planetary differential drive device(China Machine Publications, Beijing 2009).

[2] Chen xiuning, in: Fundamentals of Machine Design (Zhejiang University Publications, Hangzhou 1999).

[3] Zhang E, in: Optimization design of mechanical engineering(Science Publications, Beijing 2008).

[4] Zhang Zhiyong, in: Proficient in MATLAB R2011a(Beiheng University Publications, Beijing 2011).

[5] Chen Lide, in: Fundamentals of Machine Design(China Machine Publications, Beijing 2007).
