Analysis of Steel Rope Shock Absorber Amplitude Frequency Characteristics under the Basic Excitation

Abstract:

In this paper, the differential equations of the steel rope shock absorber are established under the basic excitation, using the Fourier series expansion method and the Harmonic balance method, the corresponding frequency response equations are derived, then their numerical solutions is got, and the influence of the mass, damping, stiffness, and hysteretic force on the frequency response characteristic is analyzed under the basic excitation. It can be drawn by analyzing and comparing. Under the basic excitation, with the basic simplified mass increasing, the natural frequency will decrease, while the resonance amplitude will increase. With the steel rope damping, stiffness and the foundation damping increasing, the natural frequency will not change significantly, while the resonance amplitude will decrease. With the foundation stiffness increasing, the natural frequency and the resonance amplitude will increase significantly. The equipment mass and steel rope hysteretic force have no significant effect on the frequency response characteristics.

• Periodical: Applied Mechanics and Materials (Volume 312)
• Pages: 287-291
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.312.287
• Online since: February 2013
• Authors: Yan Ping Zhao, Zi Long Zhao, Guo Yun Lu
• Keywords: Frequency Response Characteristic, Harmonic Force Excitation, Steel Rope Shock Absorber, Two Freedom System

References

[1] Den Hartog J P. Forced Vibration with Combined Coulomb and Viscous Friction[J]. Transactions of the ASME, APM,1931,53(9):107-115

DOI: 10.1115/1.4022656

[2] Yeh G C K. Forced Vibrations of a Two-Degree-of-Freedom System with Combined Coulomb and Visous Damping [J]. J of the Ascoust Scoc of AM, 1966, 39(1):14-24

DOI: 10.1121/1.1909863

[3] Zhangqiangxing, Sainsbury M G. simplify of the dry friction excitation system [J], Journal of Vibration and Shock, 1987, 6(1):42-58.

[4] Dongzhifa, Zhangqiangxing. The Numerical Experiment of Bilinear Hysteretic System. [J], Journal of Vibration and Shock,1989,8(1):36-43.

[5] Baihongbo, Zhangpeilin, Huangxieqing. Iteration calculation method research of Hysteretic dynamic vibration absorbers under harmonic excitation response[J], Mechanical Science and Technology, 2000,19(6):902-903.

[6] Baihongbo,Zhangpeilin,Zhengjian.Hysteretic Vibration System and Engineering Application[M],Science Press, 2002,1-121.

[7] Wushanyue, Zhushijian, Huangyingyun. Research on the shock load characteristic model of a wire-cable vibration isolator [J]；Journal of Ship Mechanics, 2009, 13(1):121-127
