EKF-Based 6D SLAM for Air-Duct Cleaning Robot Using Inertial Sensor and Stereo Vision

Abstract:

The air-duct cleaning robot (ADCR) is an effective and safe tool for accomplishing terrible cleaning work in an air-duct network. In this paper, a six-dimensional simultaneous localizing and mapping algorithm based on multi-sensor information fusion is proposed to improve the ADCR's autonomous ability in unknown duct environment. By combing an inertial measurement unit (IMU) with a stereo camera and fusing the measurements of sensors with the extended Kalman filter, the uncertainty of measurement caused by noises can be bounded in a low level. Furthermore, the performance of the proposed scheme was proved to be accurate and robust with experiments in an experimental ventilation-duct environment.

• Periodical: Applied Mechanics and Materials (Volumes 313-314)
• Pages: 941-945
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.313-314.941
• Online since: March 2013
• Authors: Cong Wang, Wei Sun, De Xu Bu, Zhi Wei Zhou
• Keywords: Air-Duct Cleaning Robot, EKF, Inertial Navigation, SLAM, Stereo Vision

References

[1] B. Wu, W. Sun and M. Ouyang. Duct Cleaning Robot Comprehensive Kinematics Modeling and Analysis Considering the Complex Terrain. Advanced Materials Research, 2012, 430:2032- 2036.

DOI: 10.4028/www.scientific.net/amr.430-432.2032

[2] Y. Cao, H.G. Chen, X.J. Yu, H.H. Zang and X.J. Li. Machine Vision-Based Detection System of a Cleaning Robot for Vertical Type Air-Conditioning Duct. in Proceedings of the 2nd International Conference on Advanced Computer Control, Shenyang, China, March, 2010, pp.545-548.

DOI: 10.1109/icacc.2010.5487164

[3] M. Johnson-Roberson, O. Pizarro, S.B. Williams and I. Mahon. Generation and Visualization of Large-Scale Three-Dimensional Reconstructions from Underwater Robotic Surveys. J. Field. Robot., 2010, 27(1):21-51.

DOI: 10.1002/rob.20324

[4] V. Sazdovski and P.M.G. Silson. Inertial Navigation Aided by Vision-Based Simultaneous Localization and Mapping. IEEE Sens. J., 2011, 11(8):1646-1656.

DOI: 10.1109/jsen.2010.2103555

[5] G. Bleser and D. Stricker. Advanced Tracking through Efficient Image Processing and Visual-Inertial Sensor Fusion. Comput. Graph-UK., 2009, 33(1):59-72.

DOI: 10.1016/j.cag.2008.11.004

[6] F.M. Mirzaei and S.I. Roumeliotis. A Kalman Filter-Based Algorithm for IMU-Camera Calibration: Observability Analysis and Performance Evaluation. IEEE T. Robot., 2008, 24(5):1143-1156.

DOI: 10.1109/tro.2008.2004486

[7] F.A. Moreno, J.L. Blanco and J. Gonzalez. Stereo Vision Specific Models for Particle Filter-Based SLAM. Robot. Auton. Syst., 2009, 57(9):955-970.

DOI: 10.1016/j.robot.2009.03.002
