Usage of Magnetorheological Damper in Active Front Bumper System for Frontal Impact Protection

Abstract:

In this paper, the effectiveness of the active bumper system to reduce the jerk of a vehicle during collision is discussed. The mathematical model is done by using MATLAB 7.0 to simulate a collision between a pendulum and a vehicle installed with the active bumper system. In the active bumper system, it consists of three parts which are magnetorheological(MR) model, inner controller and outer loop controller. The validated model is used to develop an inner loop controller by implementing a close-loop PI control to track the desired damping force through simulation. The governing equations of motions of vehicle collision and MR damper model are then integrated with the well known control strategy namely skyhook control. The performance of skyhook control is then compared with the vehicle with passive damper and common vehicle by using computer simulation in order to reduce the acceleration and the jerk of the vehicle during collision.

• Periodical: Applied Mechanics and Materials (Volume 315)
• Pages: 40-44
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.315.40
• Online since: April 2013
• Authors: Alif Zulfakar bin Pokaad, Khisbullah Hudha, Md Radzai bin Said
• Keywords: Active Front Bumper, Magnetorheological (MR) Damper, Skyhook Controller

References

[1] Rekveldt, M.G.C., (2003), Literature Survey on in-Vehicle Safety Devices, TNO report 03. OR. BV. 037. 1/MRE.

[2] Bonnel, M., Pointer, S., Bodurtha, E., and Castro, R., (2004), The Active Bumper System, Department of Mechanical, Industrial and Manufacturing Engineering College of Engineering, Northeastern University.

[3] Ahmadian, M., (1999), On the Isolation Properties of Semiactive Dampers, Journal of Vibration and Control, 5(2), p.217 – 232.

DOI: 10.1177/107754639900500204

[4] Hong, S.R., Choi, S.B., Choi, Y.T., and Wereley, N.M., (2005), Non-Dimensional Analysis and Design of a Magnetorheological Damper, Journal of Sound and Vibration, 288, pp.847-863.

DOI: 10.1016/j.jsv.2005.01.049

[5] Karnopp, D., (1990), Design Principles for Vibration Control of Systems Using Semi-Active Dampers, Transactions of the ASME, Vol. 112, pp.448-455, September.

DOI: 10.1115/1.2896163

[6] Besinger, F. H., Cebon, D., and Cole, D. J., (1995), Force Control of a Semi-Active Damper, Journal of Vehicle System Dynamics, 24, p.695–723.

DOI: 10.1080/00423119508969115

[7] Choi, Y.T., and Werely, N., (2008), Shock Isolation Systems Using Magnetorheological Dampers, Journal of Vibration and Acoustics, Vol. 130 / 024503-1.

[8] Alif Z., Hudha K., Nasir Z., and Ubaidillah. (2011) Simulation and Experimental Studies on the Behavior of a Magnetorheological Damper under Impact Loading. International Journal of Structural Engineering, Vol. 2 No. 2 pp.164-187.

DOI: 10.1504/ijstructe.2011.039422

[9] Hudha, K., Jamaluddin, H., and Samin, P.M., (2005), Effects of Control Techniques and Damper Constraint on the Performance of a Semi-Active Magnetorheological Damper, International Journal of Vehicle Autonomous Systems, Vol. 3, Nos. 2/3/4.

DOI: 10.1504/ijvas.2005.008235
