Dynamic Performance Measurement and Modeling for a Prototype Accessory Drive System with Three Pulleys and One Tensioner

Abstract:

Accessory drive systems with tensioner have been wildly used in the automotive industry to drive accessories. At first, an experimental investigation of dynamic performance for a prototype accessory drive system (including one driving pulley, one driven pulley and one tensioner) is conducted. The experimental set-up is introduced in detail. The driven pulley speeds, radial force of tensioner pulley hub, transverse placement of belt span and angular placement of tensioner arm are measured with driving pulley speeds. It is analyzed that the influence of the speeds and vibration amplitudes of driving pulley on the dynamic performance. At last, the modeling methods for accessory drive system produced in previous studying by author are validated by comparing with experimental data.

• Periodical: Applied Mechanics and Materials (Volume 318)
• Pages: 200-206
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.318.200
• Online since: May 2013
• Authors: Hong Yun Wang, Ji Yong Zhao, Wen Bin Shangguan
• Keywords: Accessory Drive System, Dynamic Performance Measurement, Modeling

References

[1] C.R. Barker, L.R. Oliver, W. F. Brieg, Dynamic analysis of belt drive tension forces during rapid engine acceleration, SAE conference, 910687(1991), 239-254.

DOI: 10.4271/910687

[2] T.C. Kraver, G.W. Fan, J.J. Shah, Complex modal analysis of a flat belt pulley system with belt damping and coulomb-damped tensioner, Journal of Mechanical Design. 118(1996), 306-311.

DOI: 10.1115/1.2826885

[3] L. Zhang, J.W. Zu, Modal analysis of serpentine belt drive systems, Journal of Sound and Vibration. 222(1999), 259-279.

DOI: 10.1006/jsvi.1998.2078

[4] L. Kong, R.G. Parker, Equilibrium and belt-pulley vibration coupling in serpentine belt drives, Journal of Applied Mechanics. 70(2003), 739-750.

DOI: 10.1115/1.1598477

[5] R.G. Parker, Efficient eigensolution, dynamic response, and eigensensitivity of serpentine belt drives, Journal of Sound and Vibration. 270(2004), 15-38.

DOI: 10.1016/s0022-460x(03)00259-1

[6] L. Kong, R.G. Parker, Coupled belt-pulley vibration in serpentine drives with belt bending stiffness, Journal of Applied Mechanics. 71(2004), 109-119.

DOI: 10.1115/1.1641064

[7] M.J. Leamy, Influence of dry friction in the dynamic response of accessory belt drive system, The University of Michigan, PhD Paper, Michigan(1998).

[8] M.J. Leamy, N.C. Perkins, Nonlinear periodic response of engine accessory drives with dry friction tensioners, Journal of Vibration and Acoustics. 120(1998), 909-916.

DOI: 10.1115/1.2893919

[9] S.J. Hwang, N.C. Perkins, A.G. Ulsoy, Rotational response and slip prediction of serpentine belt drives systems, Journal of Vibration and Acoustics. 116(1994), 71-78.

DOI: 10.1115/1.2930400

[10] A.G. Ulsoy, J.E. Whitesell, M.D. Hooven, Design of belt-tensioner systems for dynamic stability, Journal of Vibration and Acoustics. 107(1985), 282-290.

DOI: 10.1115/1.3269258

[11] R.S. Beikmann, N.C. Perkins, A.G. Ulsoy, Design and analysis of automotive serpentine belt drive systems for steady state performance, Journal of Mechanical Design. 119(1997), 162-168.

DOI: 10.1115/1.2826231

[12] R.S. Beikmann, N.C. Perkins, A.G. Ulsoy, Free vibration of serpentine belt drive systems, Journal of Vibration and Acoustics. 118(1996), 406-413.

DOI: 10.1115/1.2888197

[13] R.S. Beikmann, N.C. Perkins, A.G. Ulsoy, Nonlinear coupled vibration response of serpentine belt drive systems, Journal of Vibration and Acoustics. 118(1996), 567-574.

DOI: 10.1115/1.2888336

[14] Wang Hongyun, Shangguan Wenbin, Tensioner vibration and belt slipping behavior investigation for damped serpentine belt drive systems, Journal of Beijing Institute of Technology. 19(2010), 25-30.
