Downhole Propulsion/Steering Mechanism for Wellbore Trajectory Control in Directional Drilling

Abstract:

Advanced directional drilling, especially rotary steerable systems, provides directional control of wellbore while continuously rotating the drill bit. Downhole propulsion/steering mechanism is one of the key components in rotary closed-loop drilling system. Downhole steering/propulsion mechanisms currently used for directional control include adjustable stabilizer, steerable downhole motor and steering actuators used in state-of-the-art rotary steerable systems. The novel electro-mechanical propulsion and steering mechanisms are introduced, in order to produce downhole weight on bit (WOB) and directional control of the drill bit while rotating it as well. The mechanisms are based on high-reduction ratio planetary gear system and DC motor. This propulsion/steering mechanism introduces a unique rotary steering method with a manner of turning screw inside borehole. As a downhole propulsion/steering mechanism, it can be integrated with an existing MWD system to provide directional control and downhole propulsion force on drill bit.

• Periodical: Applied Mechanics and Materials (Volume 318)
• Pages: 185-190
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.318.185
• Online since: May 2013
• Authors: Xu Hui Liu, Ying Hui Liu, Ding Feng
• Keywords: Directional Control, Mechanical Design, Self-Propelled, Steerable, Steering/Propulsion Mechanism

References

[1] Y. Liu, Y. Su, Automatic Inclination Controller: a New Inclination Controlling Tool for Rotary Drilling. IADC/SPE 59259, Proceedings of the 2000 SPE/IADC Drilling Conference, New Orleans, 2000, pp.23-25.

DOI: 10.2118/59259-ms

[2] S. Poli, F. Donati, J. Oppelt and D. Ragnitz, Advanced Tools for Advanced Wells: Rotary Closed-Loop Drilling System – Results of Prototype Field Testing, SPE Drilling & Completion. 4 (2000) 67-72.

DOI: 10.2118/36884-pa

[3] U. Hahne, G. Risdal, J. Ruszka and L.S. Wahlen, Integrated BHA Concept of the Latest Generation Rotary Closed-Loop System for Hole Sizes from 5 7/8" to 18 1/4", IADC/SPE 87168, the SPE/IADC Drilling Conference, Dallas, 2004, pp.2-4.

DOI: 10.2118/87168-ms

[4] B. J. Patton, Automatic Directional Drilling Shows Promise, Petroleum Engineer International. 4 (1992) 44-48

[5] S. Schaaf, C.R. Mallary, Point-the-Bit Rotary Steerable System: Theory and Field Results, SPE 73247, the 2000 SPE Annual Technical Conference and Exhibition, Dallas, 2000, pp.1-4.

DOI: 10.2118/63247-ms

[6] T. Yonezawa, E.J. Cargill, T.M. Gaynor, J.R. Hardin, R.T. Hay, A. Ikeda and Y. Kiyosawa, Robotic Controlled Drilling: A New Rotary Steerable Drilling System for the Oil and Gas Industry, IADC/SPE 74458, the IADC/SPE Drilling Conference, Dallas, 2002, pp.26-28.

DOI: 10.2118/74458-ms

[7] A. C. Odell, Application of a Highly Variable Gauge Stabilizer at Wytch Farm to Extend the ERD Envelope, SPE 30462, the SPE Annual Technical Conference and Exhibition, Dallas, 1995, pp.22-25.

DOI: 10.2118/30462-ms

[8] A. Eddison, J. Symons, Downhole Adjustable Gauge Stabilizer Improves Drilling Efficiency in Directional Wells, SPE 20454, the 65th SPE Annual Technical Conference and Exhibition, New Orleans, 1990, pp.23-26.

DOI: 10.2118/20454-ms

[9] S. Bell, Innovative Methods Lower Drilling Costs, Petroleum Engineer International. 2 (1993) 25-26.

[10] Y. Liu, B. Weinberg and C. Mavroidis, Design and Modeling of the NU Smart Space Drilling System (SSDS), Proceedings of the 10th ASCE Aerospace Division International Conference on Engineering, Construction and Operations in Challenging Environments, Houston, 2006, pp.5-8.

DOI: 10.1061/40830(188)96

[11] Y. Liu, B. Weinberg and C. Mavroidis, Mechanical Design and Modeling of a Planetary Robotic Drilling System, Proceedings of the ASME 2006 International Design Engineering Technical Conference & Computers and Information in Engineering Conference, Philadelphia, 2006, pp.10-13.

DOI: 10.1115/detc2006-99699

[12] M. Badescu and C. Mavroidis, Workspace Optimization of 3-Legged UPU and UPS Parallel Platforms with Joint Constraints, Journal of Mechanical Design. 126 (2004) 291-300.

DOI: 10.1115/1.1667922
