The Numerical Simulation of Hydraulic Transmission in the Process of Coalbed Methane (CBM) Wells Drainage in the South Block of Shizhuang

Abstract:

Based on the data of CBM vertical well’s exploration and development in the south block of Shizhuang. This paper applies the method of comparison and adopts the software Visual Modflow4.2. The software simulated the 8th well whose original permeability and modified permeability is both poor and the groups of wells when draining for the rule of hydrostatic transmission. Results show that the relationship between original permeability and modified permeability determine the track of hydraulic transmission. When single well is draining, the hydraulic transmission can be seen as several concentric circles whose center is wellbore, but when the groups of wells are draining, regularity is the change of water level is not obvious because of the heterogeneity of coal reservoir. After draining for a long time, the water level difference between drained area and not drained area has appeared. The potential energy of underground water has a trend that overall downward, but did not form effective interference between the wells. Therefore, the original permeability and modified permeability become the key factor whether a region has high yield or not.

• Periodical: Applied Mechanics and Materials (Volume 318)
• Pages: 541-546
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.318.541
• Online since: May 2013
• Authors: Xiang Hao Wang, Yan Bin Wang, Sha Sha Gao, Jia Hui Cheng, Hui Jie Xu, Jing Wu
• Keywords: Coalbed Methane (CBM), Drainage, Hydraulic Pressure, Numerical Simulation

References

[1] Gao Lu, Kang Tianhe, Lu Wei. Experimental study on the infuluence of affusion stress confining pressures and immersion times on the water content in coal body, Shanxi Coal. 30(2010)43-45.

[2] Duan Kanglian, Zhao Yangsheng, Hu Yaoqing. A study on consolidation deformation of coal caused by pore water pressure, Journal of China Coal Society.20(1995)139-143.

[3] Zhang Zhancun, Ma Piliang.Experimental on moisture effects on the gas absorption speciality of different kinds of coal, Journal of China Coal Society.33(2008)141-147.

[4] Feng Zengchao, Zhao Dong, Zhao Yangsheng.Experimental tudy on impact of water ratio adsorption of lump coal, Chinese Journal of Rock Mechanics and Engineering. 28(2009)3291- 3295.

[5] Zhang Shiyin, Sang Shuxun.Influence mechanism of liquid water on methane absorption of coals with different ranks, Acta Geologica Sinica. 82(2008) 1350-1354.

[6] Joubert J I. Effect of moisture on the methane capacity of American coals. Fuel, 53(1974) 186-191.

DOI: 10.1016/0016-2361(74)90009-x

[7] Zhao Jin, Zhang Sui-an. Study on pressure drop transmission law of coal bed methane drainage reservoir stratum, Coal Science and Technology. 40(2012) 65-68.

[8] Sun Qiang, Sun Jianping, Zhang Jian,et al., CBM Geological Characteristics in Shizhuang South Block, Southern Qinshui Basin, Coal Geology of China. 22(2010)9-12.

[9] Feng Qingtai. The Geological Characteristics of CBM Reservoir of Southern Shizhuang in Qinshui Basin, Journal of Shanxi Datong University(Natural Science Edition). 28(2012) 72-78.
