Effect of Track Measuring Beam on the Dynamic Properties of Rail Inspection Car

Abstract:

The track measuring beam is installed in the bogie frame to measure the geometry parameters of the rail. In this paper, the dynamic model of the inspection car was established in order to compare the dynamic properties of the vehicle with and without track measuring beam installation. The motion stability, ride quality, vibration acceleration and curve negotiation performance of the vehicle after the track measuring beam installed were investigated. The results show that after the track measuring beam installation the critical velocity of the inspection car decreases, but the running at speed of 120km/h can be guaranteed. The track measuring beam has no influence on the ride quality and curve negotiation performance and the effect of it on vibration mode is little.

• Periodical: Applied Mechanics and Materials (Volumes 321-324)
• Pages: 27-32
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.321-324.27
• Online since: June 2013
• Authors: Long Fa Wu*, Hao Dong
• Keywords: Dynamic Propertry, Track Inspection Car, Track Measuring Beam, Vibration Mode

References

[1] Ren Zhiqiang, The Application of GJ-5 Type High-Speed Track Inspection Car in the Track Irregularity Test, Southwest Jiaotong University, 2011.3

[2] Zhou Jinsong, Lu Zhenggang, Yang Guozhen, The Research on Track Measuring Beam Design of Combined Safety Inspection Car, China Railway Science, 22(6): 13-16.

[3] Frank Brennecke, Dynamic Analysis of Shock Isolated Beam Mount Assembly For Track Geometry Measurement Instruments, Structural Analysis, Inc.Austin, Texas.

[4] Wang Futian, Vehicle System Dynamics, China Railway Press, 1994: 12-16.

[5] Zeng Jing, Numerical Computations of the Hunting Bifurcation and Limit Cycles for Railway Vehicle System , Journal of the China Railway Society, 1996,3: 13-19.

[6] Traction Power State Key Laboratory, 3rd Vehicle Dynamics Property of Inspection Car at Shuohuang Railway, Southwest Jiaotong University, 2012.10.
