670nm Single Wavelength Nd:YAG Ceramic Laser

Abstract:

The Nd:YAG ceramic laser at 670 nm was studied by means of dispersion prism and KTP intracavity-frequency-doubling. We designed and optimized the cavity parameters by MatrixLaser software based on the standard ABCD ray propagation matrix. By using the laser diode arrays side-pumped Nd:YAG ceramic crystal with Nd doping concentration of 1.1at% and dimension of Φ3×50 mm, the Nd:YAG ceramic laser at 670 nm was realized. Under repetition rate of 1 000Hz and single pulse pumped energy of 144 mJ, the output energy of 5.1mJ at 670 nm is obtained. The optic-optic efficiency is 3.54%. The results not only formed the basis for the further development of the high power and high efficiency ceramic red laser, but also provided a great prospect for the high power ceramic red laser in the field of medical treatment, color display and other areas of application.

• Periodical: Applied Mechanics and Materials (Volumes 321-324)
• Pages: 482-485
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.321-324.482
• Online since: June 2013
• Authors: Zhi Chao Wu, Xiu Li Zhang
• Keywords: 670nm Single Wavelength, Intracavity Frequency-Doubling, Nd:YAG Ceramic

References

[1] A. Ikesue, Polycrystalline Nd:YAG ceramic lasers, Optical Materials. 19 (2002) 183-187.

[2] Revital Feldman, Yuval Golan, Zeev Burshtein, Steven Jackel, Inon Moshe, Avi Meir, Yaakov Lumer, Yehoshua Shimony, Strengthening of poly-crystalline (ceramic) Nd:YAG elements for high-power laser applications, Optical Materials. 33 (2011) 695-701.

DOI: 10.1016/j.optmat.2010.09.013

[3] J. B. Gruber, D. K. Sardar, R. W. Yow, T. H. Allik, B. Zandi, Energy-level structure and spectral analysis of Nd3+ in polycrystalline ceramic garnet Y3Al5O12, Appl. Phys. 96 (2004) 3050.

DOI: 10.1063/1.1776320

[4] T. Taira, C. R. "Ceramic YAG lasers," Phys. 8 (2007) 138-152.

[5] Sungman Lee, Daewook Choi, Cheol-Jung Kim, Jun Zhou, Highly efficient diode side -pumped Nd:YAG ceramic laser with 210W output power, Optics & Laser Technology. 39 (2007) 705-709.

DOI: 10.1016/j.optlastec.2006.03.015

[6] J. Kong, Z. Zhang, D. Tang, et al., Diode end-pumped passively Q-switched Nd:YAG ceramic laser with Cr4+:YAG saturable absorber, Laser Physics. 18 (2008) 1508-1511.

DOI: 10.1134/s1054660x08120189

[7] Lu J, Yagih, Ta Kaichi K, et al., 110 W ceramic Nd3+:Y3Al5O12 laser, Applied Physics B. 10 (2004) 1007-1009.

[8] C.Y. Li, Y. Bo, B.S. Wang, C.Y. Tian, Q.J. Peng, D.F. Cui, Z.Y. Xu, W.B. Liu, X.Q. Feng, Y.B. Pan, A kilowatt level diode-side -pumped QCW Nd:YAG ceramic laser, Optics Communications. 283 (2010) 5145-5148.

DOI: 10.1016/j.optcom.2010.07.045

[9] Wenbin Liu, Di Zhang, Jiang Li, Yubai Pan, Yong Bo, Chaoyang Li, Baoshan Wang, Qinjun Peng, Dafu Cui, Zuyan Xu, High power single wavelength ceramic Nd:YAG laser at 1116 nm, Optics & Laser Technology. 46 (2013) 139-141.

DOI: 10.1016/j.optlastec.2012.05.027

[10] T. Omatsu, A. Minassian, M.J. Damzen, Passive Q-switching of a diode-side-pumped Nd doped 1.3μm ceramic YAG bounce laser, Opt. Commun. 282 (2009) 4784-4788.

DOI: 10.1016/j.optcom.2009.09.017

[11] Wang Pengfei, Lü Baida, The influence of folded- resonator parameters on the stability of intracavity- frequency-doubled laser, Laser Technology. 27 (2003) 328-330.

[12] Wang Juan-juan, Wang Jia-xian, LD-pumped Nd:YVO4/KTP frequency-doubled red laser with folded resonator, Journal of Applied Optics. 29 (2008) 67-71.
