Study on the Screw Rotor Profile of Non-Leakage Dry Screw Vacuum Pump

Abstract:

Through mathematical derivation based on screw engagement theory, the complete equations of the rotor profile with single thread, fixed pitch screws, trapezium and concave tooth surface were given. The end face profile of the pair screw rotor is conjugate and identical. The pair screw rotor form a meshing relationship by left hand and right hand. Finally, through modeling and simulation of meshing process by PRO/ENGINEER software, the profile equation is proved to be correct, the meshing line is completed, and operating the tooth surface interference does not occur in the course of meshing process.
