Study on Propagation Characteristics of EM Wave of PD in Cable Accessories

Abstract:

PD in cable accessories will inspire EM waves of ultra-high frequency (UHF) at hundreds of MHZ to GHZ. To study the characteristics of EM wave inspired by PD in cable accessories, a three-dimension model of 110kV cable joints is established. Based on the propagation theory of EM waves in coaxial waveguide, finite element method (FEM) is used to analyze the effect of cable joints composite interfaces on UHF signal propagation, and simulation analysis of relations between PD UHF signal's energy distribution, pulse frequency, propagation distance. Simulation results show that the main transmission mode of EM waves is TEM mode in the joints; Energy of EM waves descends rapidly as the PD pulse's frequency increases; Energy of TEM waves descends rapidly with the increasing detection distance. Simulation analysis of UHF signal's propagation characteristics provides the theoretical basis for UHF PD detection in cable accessories.

• Periodical: Applied Mechanics and Materials (Volumes 325-326)
• Pages: 610-614
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.325-326.610
• Online since: June 2013
• Authors: Qian Shi, Feng Wang, Ting Ting Fu, Yan Miao
• Keywords: Cable Accessories, Electromagnetic Waves (EMW), Finite Element Method (FEM), Partial Discharge (PD), UHF

References

[1] YANG Jun, ZHANG Zhe, YIN Xiang-gen, et al. Application of high temperature superconducting cable in power systems [J]. Power System Technology, 2004, 28(21): 63-68.

[2] S.Chandrasekar, A.Cavallini and G.C. Montanari. Bandwidth and sensitivity issues in PD detection in power cables[J]. IEEE Trans. on Electrical Insulation, Vol.14, No.3, 2007:735-743.

DOI: 10.1109/tdei.2007.369538

[3] HUANG Xing-quanl, KANG Shu-yin, LIHong-zhi. Research on Ultra-High-Frequency Method for Detection of Partial Discharge in GIS [J]. Electrical network technology, 2006, 30(7): 37_40

[4] S. Sakaguchi, M. Oyama. Application of Maxwell Solvers to PD Propagation Part III: PD Propagation in GIS [J]. IEEE Electrical Insulation Magazine, 2003, 19(1):6-12.

DOI: 10.1109/mei.2003.1178103

[5] Denissov D, Kohler W, Tenbohlen S, et al, Simulation of UHF PD Wave Prooagation in Plug-in Cable Terminations. IEEE Electrical Insulation, 8(6):547-550, (2008)

DOI: 10.1109/elinsl.2008.4570392

[6] Judd M D, Hampton B F, Farish O. Modelling Partial Discharge Excitation of UHF Signals in Waveguaid Structures Using Green's Functions. IEE Proc-Sci Meas Technol, 1996,143(1): 63-70

DOI: 10.1049/ip-smt:19960029

[7] GONG Ning-tao. Study on Wide-band Detecting for Partial Discharge in 110kV XLPE Prefabricated Cable Joints.[D] Chongqing University.2009.

[8] Judd M D, Farish O and HamptonB F．The Excitation of UHF signals by partial discharge In GIS[J]．IEEE Trans on Dielectrics and Electrical Insulotion, 1996, 3(2):213-228

DOI: 10.1109/94.486773
