Influence of Bonding Quality for Piezoelectric Sensors with Applications to Lamb Wave Damage Detection

Abstract:

In this paper, the propagation characteristics of Lamb waves activated and collected by piezoelectric sensors bonded on an aluminum panel were investigated both theoretically and experimentally on different bonding cases. The bonding layer is an intermedium of energy transmission between structure and sensor. The bonding quality heavily effects on the lamb propagation characteristics, including frequency dispersion, mode conversion, and signal amplitude. In particular, the variation of the surface strain with frequency for symmetric lamb mode was studied in different bonding quality. A sensor bonding quality evaluation method based on frequency response characteristics of the surface strain was developed to compensate the sensor network. The proposed approach can provide a useful reference for structural health monitoring strategy formulation.

• Periodical: Applied Mechanics and Materials (Volume 330)
• Pages: 494-499
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.330.494
• Online since: June 2013
• Authors: Dong Yue Gao, Zhan Jun Wu, Yi Shou Wang, Ke Hai Liu
• Keywords: Bonding Quality, Lamb Wave, Piezoelectric Sensors, Structural Health Monitoring Strategy

References

[1] Giurgiutiu, V., Tuned Lamb wave excitation and detection with piezoelectric wafer active sensors for structural health monitoring. Journal of Intelligent Material Systems and Structures, 2005. 16(4): pp.291-305.

DOI: 10.1177/1045389x05050106

[2] Belmans, R.J.M., et al., Electro-mechanical analysis of the audible noise of an inverter-fed squirrel-cage induction motor. Industry Applications, IEEE Transactions on, 1991. 27(3): pp.539-544.

DOI: 10.1109/28.81839

[3] Liang, C., F. Sun and C.A. Rogers, Electro-mechanical impedance modeling of active material systems. Smart Materials and Structures, 1996. 5: p.171.

DOI: 10.1088/0964-1726/5/2/006

[4] di Scalea, F.L., H. Matt and I. Bartoli, The response of rectangular piezoelectric sensors to Rayleigh and Lamb ultrasonic waves. The Journal of the Acoustical Society of America, 2007. 121: p.175.

DOI: 10.1121/1.2400668

[5] Yu, L., G. Bottai-Santoni and V. Giurgiutiu, Shear lag solution for tuning ultrasonic piezoelectric wafer active sensors with applications to Lamb wave array imaging. International Journal of Engineering Science, 2010. 48(10): pp.848-861.

DOI: 10.1016/j.ijengsci.2010.05.007

[6] Lanzara, G., et al., Influence of interface degradation on the performance of piezoelectric actuators. Journal of Intelligent Material Systems and Structures, 2009. 20(14): pp.1699-1710.

DOI: 10.1177/1045389x09341198

[7] Rose, J.L. and P.B. Nagy, Ultrasonic waves in solid media. The Journal of the Acoustical Society of America, 2000. 107: p.1807.

[8] Rose, J.L., A baseline and vision of ultrasonic guided wave inspection potential. TRANSACTIONS-AMERICAN SOCIETY OF MECHANICAL ENGINEERS JOURNAL OF PRESSURE VESSEL TECHNOLOGY, 2002. 124(3): pp.273-282.

DOI: 10.1115/1.1491272

[9] Lin, X. and F.G. Yuan, Diagnostic Lamb waves in an integrated piezoelectric sensor/actuator plate: analytical and experimental studies. Smart Materials and Structures, 2001. 10: p.907.

DOI: 10.1088/0964-1726/10/5/307
