Stress Calculation of a Spherical Tank on Settled Ground Based on FEM

Abstract:

In this paper, a model of a LGP spherical tank supported by 8 equator tangent-type supporting on settled ground was built.The stress on the shell,on the pillars and on the connection of pillars with shell were calculated,the stress distribution on shell,pillars and the connection of pillars with shell were obtained, the influence of foundation settlement to the stress of shell and pillars were studied. The results showed that the differential settlement produced a less affect on the shell,but a greater impact on the pillars. The maximum stress arose at the connection between pillars and shell ,there is a big stress area in the connectors area.

• Periodical: Applied Mechanics and Materials (Volume 331)
• Pages: 110-113
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.331.110
• Online since: July 2013
• Authors: Hong Li Gao, Wei Jun Li, Zhi Hai Li
• Keywords: Differential Settlement, Pillar, Slant, Spherical Tank, Stress

References

[1] GB 12337-1998, Steel spherical tanks, edtied by National quality technology supervision bureau(1998)

[2] Y Xu，Y F Yang, P Zhu，et al. Spherical Tank and large tanks, edtied by Chemical Industry Press.(2005), in press.

[3] J G Huang, Y T Li, L Q Shi,et al. Analysis and Calculation of Pillars and Rods in Slanted Spherical Tank on Settled Ground, Process Equipment & Piping, Vol. 45(2008), p.18

[4] Y T Li,J G Huang,J J Tan, et al. Horizontal Stiffness of Spherical Tank as a Whole and Stress Analysis of Tie-rod between Support,Pressure vessel Technology, Vol. 30(2006),p.34

[5] B B Zhou,W Tan,P Z Yang, Influence of Different Uneven Subsidence Patterns of Foundation on the Loading Conditions of Support Legs on a Spherical Tank, Petro-Chemical Equipment, Vol.38(2009),p.12

[6] H Q Mao, Stability analysis of pillars of spherical tanks for ammonia, Chemical Engineering & Machinery, Vol.24(1997),p.104

[7] W Xie,The Influence of Foundations Subsidence Differences on the Stability of Bracings of Spherical Tanks, Pressure vessel Technology,Vol.18(2001),p.45

[8] F Lu, S J Zhao, Large-Sized Spherical Tank's Design by FEA Stress Analysis, Cfhi Technology,Vol.134(2010),p.17

[9] Q S Li,Stress analysis of sperical tanks,Petroleum Refinery Engineering,Vol.42 (2012),p.61

[10] H L Gao,W J Li, Z H Li, Stress Analysis of a LPG Spherical Tank on Multiple Differential Settled Ground,Pressure vessel Technology, Vol.30(2013),p.40
