Lapping Aspheric Workpiece Using Bending Method

Abstract:

A new method is proposed that high speed lapping aspheric surface workpiece using lapping tool by means of bending because there processing difficult, In this study, the principle of high speed lapping has been presented, the mathematical model for the lapping tool has been established, and the equidistance curve error of the lapping tool has been analyzed. The results of the experiment indicate that the forming precision of the lapping tool is high using this method, the surface precision of the workpiece reaches micron grade, furthermore, the aspheric surface workpiece can been machined using this method in lapping, and that it can meet the need of medium precision of machining the aspheric surface workpiece. The experiment result indicates that the the lapping tool shape precision is high, the lapping error of the workpiece is 0.0108mm, and lapping efficiency is high and the cost is low. This aspheric lapping method has incomparable superiority of other processing methods.

• Periodical: Applied Mechanics and Materials (Volume 331)
• Pages: 595-599
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.331.595
• Online since: July 2013
• Authors: Chun Min Shang, Dong Mei Zhang, Jian Dong Yang
• Keywords: Aspheric Surface, Bending Method, High Speed Lapping, Shape Error

References

[1] Yang Jiandong, Tian Chunlin high-speed grinding technology. Beijing: National Defense Industry Press, 2003(in Chinese).

[2] Sergio Vazquez Montiel, M A Rodriguez Hernandez. Two-wavelength interferometry in the manufacture process of high-aspheric surfaces. SPIE Vol. 4419, 265-268，(2001)

[3] Tuell Michael T., Burge James H., Anderson Bill. Aspheric optics: smoothing the ripples with semi-flexible tools，Optical engineering. 2002. 41（7）:1473-1474

DOI: 10.1117/1.1481898

[4] Wang Jingtu, Yu Jingchi Zhang Xuejun, Solution for Best Fitting Spherical Curvature Radius and Asphericity of Off-Axis Aspherics. Optoelectronic Engineering, 2000,27 (3) :16-20(in Chinese).

DOI: 10.4028/www.scientific.net/kem.364-366.499

[5] Pan Junhua, optical aspheric design, processing and inspection. Beijing: Science Press, 1994. 1-5(in Chinese).

[6] Shang Chunmin. The theoretical and experimental research on high speed lapping parabolic parts. Changchun: School of Mechanical and Electrical Engineering, Changchun University of Science and Technology, 2004(in Chinese).
