Rotating Accuracy Measurement System of Spindle Based on Three Point Method

Abstract:

In order to measure the rotating machinery fault quickly and conveniently at a construction site, a new measuring system of rotating accuracy of spindle was developed according to three point method. With summarizing the principle of error separation technique based on three point method, the function, hardware construction and software module of this module were introduced. The problem of harmonic suppression is relieved by changing the sensor arrangement. The measuring system mainly consists of three eddy current sensors ,a acquisition card and a personal computer. After a few parameters were inputted, the rotation accuracy of calculation and display could be carried out automatically on line at a construction site.

You might also be interested in these eBooks

Measurement Technology and Engineering Researches in Industry

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 333-335)

Pages:

167-171

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.333-335.167

Citation:

Cite this paper

Online since:

July 2013

Authors:

Peng Qing Wang*, Hongjun Wang, He Peng Gao

Keywords:

Measuring System, Rotating Accuracy of Spindle, Three Point Method

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Aoki Y, Ozono S. On a new method of roundness measurement based on the three-point method[J]. J JSPE, 1966, 12: 27-32.

Google Scholar

[2] WHITEHOUSE D J. Some theoretical aspects of error separation techniques in surface metrology [J].J. Physics E: Scien. Instru, 1976, 9(7): 531-536.

DOI: 10.1088/0022-3735/9/7/007

Google Scholar

[3] Eric R. Marsh, David A. Arneson and Donald L. Martin. A comparison of reversal and multiprobe error separation[J]. Precision Engineering, 2010, 34(1): 85-91.

DOI: 10.1016/j.precisioneng.2009.03.001

Google Scholar

[4] Wang Xinwei, Mu Xue. Design and research of the eddy current displacement sensor measurement system based on LabVIEW[J]. Machine Tool&Hydraulics, 2009, 37(9): 160-165.

Google Scholar

[5] Wan Peng. Research of spindle system fault diagnosis method based on manifold [D]. (2013).

Google Scholar

[6] Wei Gao, Satoshi Kiyono and Takamitu Sugawara. High-accuracy roundness measurement by a new error separation method[J]. Precision Engineering 21, 123-133, (1997).

DOI: 10.1016/s0141-6359(97)00081-0

Google Scholar
