The Analysis and Correction of Time-Delay in the Precise Acoustic Measurement System

Abstract:

The acoustic transducer is a nonlinear system, which will cause a time delay to signals. The system group and phase delay have a large influence on the results in the transmit-time measurement. In order to solve the problem, this paper proposes to use the signal phase difference to eliminate the phase delay, and precisely determine the group delay by the method of experiment. At first, this paper theoretically proves that the group delay of the acoustic measurement system is constant, and the phase delay changes over signal frequency, then it analyzes the influence of group and phase delay on the measuring results and meanwhile puts forward a method to use the multi-frequency signal phase difference to eliminate group delay .Finally, it achieves the group delay through experiments, and there is a good consistency between the experimental results and theoretical analysis.

• Periodical: Applied Mechanics and Materials (Volumes 333-335)
• Pages: 236-242
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.333-335.236
• Online since: July 2013
• Authors: Zhi Gang Huang*, Chun Jie Qiao, Chao Ma, Shen Zhao
• Keywords: Acoustic Measurement System, Group Delay, Phase Delay, Transducer

References

[1] Michael J. Buckingham and Michael D. Richardson: On Tone-Burst Measurements of Sound Speed and Attenuation in Sandy Marine Sediments. IEEE Journal of oceanic engineering, Vol. 27, N0. 3, July 2002, pp.429-453.

DOI: 10.1109/joe.2002.1040929

[2] Chuntian Zhang: The Phase delay and Group delay in the delay-line of PAL. The receiving of television: pp.1-11.

[3] Weihua Dai, Chunjie Qiao, Shen Zhao, Dongsheng Li, Chao Zhou: Group-delay analysis of acoustic velocity measurement system. Sensors and Microsystems. (2012).

[4] Hongfu Zhou: Acoustic Transducer and Array. 1984, pp.11-43.

[5] Deming Lu: The principle of underwater acoustic tranducer. 2001, pp.114-251.
