An Experimental Study on Synchronizing Process of Synchronizer

Abstract:

Based on the establishment of each independent phase theoretical model during synchronizing process of synchronizer used in HEV (hybrid electrical vehicle), an experimental means to analyze that synchronizing process is put forward in this article. Firstly, alternative current impedance analyzer is adopted to obtain amplitude and phase angle information of equivalent complex impedance between engaged gear ring and synchronizing ring. There are significant changes between the obtained results when the phase transition happens. Therefore, the moment of each phase transition can be determined through the experimental data. Then, to verify the consistency of the experiment mentioned above, a series of experiments are conducted under different rotation speed differences between the driving and driven cone. The experimental results show that different rotation speed differences lead to different moments when the severe mutation of amplitude and phase angle of the equivalent complex impedance occurs. It demonstrates the validity of the experiment that the rotation speed difference which belongs to phase transition criteria has a certain influence on the phase transition process. Furthermore, it is quite consistent with the actual situation, which also verifies that the experimental method put forward in this article has certain reliability.

• Periodical: Applied Mechanics and Materials (Volumes 336-338)
• Pages: 1532-1539
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.336-338.1532
• Online since: July 2013
• Authors: Zai Min Zhong, Qiang Lv, Xue Ping Chen
• Keywords: Equivalent Complex Impedance, Experimental Means, Phase Transition, Rotation Speed Difference, Synchronizing Process

References

[1] Zhen Chen, Zaimin Zhong, Tong Zhang. Simulation Analysis on the Synchronizing Process of Synchronizer Base on ADAMS. Automotive Engineering, 2011，33(4), 340-344(In Chinese).

[2] Xiaojin Zhu, Weigong Zhang. Research and Realization of Electric Simulation for Mechanical Inertia in Vehicles Synchronizer Testing System. Automotive Engineering, 2001, 23(2), 134-138. (In Chinese).

[3] Mingjun Feng, Qing Ma, Li Wang, Lin Chen, XiaoMin Chen. AC Impedance Measurement of the Dielectric Spectra for Normal Human Blood Cells. Journal of first military medical university, 2009, 29(7), 1390-1392. (In Chinese).

[4] Wulin Qin, Wei Sun, Ying Zhang, Runqing Liu. Study on Activation Flotation of Pyrrhotine Using AC Impedance Technique. Mining and metallurgical engineering, 2009, 29(2), 32-35 (In Chinese).

[5] Jiwei Sun. The Research of the Grain Moisture Online Detection Technique Based On the Wide Frequency Excitation. Thesis for master degree. He Nan University of Technique. 2010. 5 (In Chinese).

[6] B Paffoni, R Progri, R Gras and J BloueÈt. The hydrodynamic phase of gearbox synchromesh operation: the influence of radial and circumferential grooves. Proceedings of the Institution of Mechanical Engineers, Part J: Journal of Engineering Tribology, 1997, 211(2), 107-116.

DOI: 10.1243/1350650971542354

[7] László LOVAS, Daniel PLAY. Modeling the synchronization behavior of manual car gearbox synchromesh mechanisms. 5th international multidisciplinary conference, 2009, 325-330.

[8] L Lovas, D Play, J Marialigeti and J F Rigal. Mechanical behavior simulation for synchromesh mechanism improvements. Poceeding of the Institution of Mechanical Engineers, Part D: Journal of Automobile Engineering, 2006, 220: 919.

DOI: 10.1243/09544070d21604

[9] Byoungchul Hwang, Jeehoon Ahn and Sunghak Lee. Effects of blending elements on wear resistance of plasma-sprayed molybdenum blend coatings used for automotive synchronizer rings. Surface and Coatings Technology, 2005, 194(2-3), 256-264.

DOI: 10.1016/j.surfcoat.2004.07.072
