Research on the Information Extraction of the Whole Machine Simple Model and Characteristics Reproduction

Abstract:

The static and dynamic characteristics calculating of the whole machine structure by finite element method lead to dense grid nodes, which is not conducive to rapid quantitative analysis. Therefore, a simplified model and the corresponding static and dynamic characteristics are needed. This paper presents a simplified model using key nodes kept principle and a corresponding software which reads data from resulting data file, extracts information such as coordinates, static and dynamic displacement of relevant nodes from reading data and draws simplified models of the whole machine structure and static and dynamic deformation of it. Take XK173 Vertical Milling Machine as the case research object, establish a complete machine model, analyze the static and dynamic characteristics and reproduce that using simplified model by software. The result shows that the Vertical Milling Machine nodes are reduced from the original 153 238 nodes to156 nodes. It well preserves machine structure and static and dynamic characteristics, and lays foundations for simplifying follow-up quantitative analysis.

• Periodical: Applied Mechanics and Materials (Volumes 34-35)
• Pages: 1052-1057
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.34-35.1052
• Online since: October 2010
• Authors: Qing Fu Wang, Hong Lin Zhao, Zhi Heng Wu, Guang Peng Zhang, Dong Hui Mu, Shi Guang Chen, Wei Guo Zhou
• Keywords: Characteristics Reproduction, Dynamic Characteristic, Information Extraction, Simple Model, Static Characteristic, Whole Machine Tool

References

[1] Zhao Honglin, Ding Qingxin, Zeng Ming, Liu Xuejie: Theoretic analysis on and application of behaviors of machine tool joints, Chinese Journal of Mechical Engnieering 44 12 (2008), pp.208-214.

[2] Wang Shijun, Huang Yumei, Zhao Jinjuan, Zhang Guangpeng, Wang Kai: Finite element analysis for machine tools, Journal of Chinese Mechanical 18 9 (2004), pp.1634-1636.

[3] Zhao Honglin, Wu Zhiheng, He Yanling, Liu Zhong, Liu Xuejie: Characteristic of combined interface and its fusing technology in modeling of machine tool structure, Journal of Manufacturing Technology & Machine Tool 5 (2007), pp.51-54.

[4] Zhang Guangpeng, Shi Wenhao, Huang Yumei: Analysis method of dynamic behaviors of guidway joint and its application in machine tools design, Chinese journal of mechanical engineering 38 10 (2002), pp.114-117.

DOI: 10.3901/jme.2002.10.114

[5] Zhao Yi: Research on the processing precision of whole machine tool simulation theory and method, China University of Petroleum (Beijing), Master's thesis (2008. 5), pp.5-8.

[6] Zhou Ning: ANSYS-APDL Advanced engineering application example analysis and the secondary development, China WaterPower Press. (2007), pp.63-69.

[7] Liu Sheng, Wang Guoquan, Shen Yonglin: The Development of Language C sample code, Electronic Industry Press. (2008), pp.209-223.

[8] Dave Shreiner, Xu Bo: The Programming Guide of OpenGL, Mechanical Industry Press. (2008), pp.82-86.
