Angle Measurement for Meter-Wave Radar Based on Mainlobe Multipath Jamming Suppression

Abstract:

When detecting low-attitude targets, the angular accuracy of the meter-wave radar will descend because of the multipath reflecting from ground. Since the multipath signal can be regarded as a multipath jamming coming from the mainlobe, we propose an angle measurement based on the mainlobe multipath jamming suppression. The weight of the new approach is obtained through certain constraints on the sum-difference beams, which can suppress the jamming and keep the curve of the monopulse ratio unchanged. Then form sum-difference beams and calculate the ratio of the monopulse ratio of the target. Finally, obtain the angle of the target through the determination of the smallest difference between the monopulse ratio of the target and the quiescent monopulse ratio. The method proposed in this paper can preserve good precision of the measurement angle. The result is verified by computer simulation.

• Periodical: Applied Mechanics and Materials (Volumes 347-350)
• Pages: 257-262
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.347-350.257
• Online since: August 2013
• Authors: Ying Jun Zhao, Rong Feng Li, Yong Liang Wang, Wei Jian Liu
• Keywords: Adaptive Beamforming, Mainlobe Jamming, Meter-Wave Radar, Monopulse Estimation

References

[1] Kai-Bor Yu, Murrow D J．Adaptive digital beamforming for angle estimation in jamming [J]. IEEE Trans Aerosp Electron Syst, 2001, 37(2): 508-523.

DOI: 10.1109/7.937465

[2] Liu Jun, Liu Zheng, Liu Yunfo. Elevation Angle and Multipath Fading Coefficient Joint Estimation Algorithm in VHF Radar[J]. Journal of Electronics & Information Technology, 2011, 33（1）：33-37.

[3] Wu Xiangdong, Zhang Shouhong, and Dong Mei. An aigorithm based on liner preprocessing for meter-wave rada to a target at low altitude[J]. Acta Electronica Sinica, 2006, 34(9): 1668-1671.

[4] Ziskind I and Wax M. Maximum likelihood localization of multiple sources by alternating projection[J]. IEEE Transaction on Acoustics, Speech, and Signal Processing, 1988, 36(10): 1553-1560.

DOI: 10.1109/29.7543

[5] Zoltowski M and Haber F. A vector space approach to direction finding in a coherent multipath environment[J]. IEEE Transaction on Antennas and Propagation, 1986, 34(9): 1069-1079.

DOI: 10.1109/tap.1986.1143956

[6] Liao Hui, Huang Zhongping. Monopulse estimation based on adaptive side lobe cancellation [J ]. M odern Radar, 2010, 32(5): 31-35.

[7] Liao Hui, Huang Zhongping. Conformal-pattern-based monopulse estimation algorithm[J]. Jonrnal of CAEFT, 2010, 5(3): 301-305.

[8] Chen Liang, Sheng Weixing, Ma Xiaofeng. Improved monopulse estimation algorithm based on general sidelobe canceller[J]. Journal of Data Acquisition&Processing, 2012, 27(3): 309-313.

[9] Jiang Yicheng, Yu Chunxi. A Novel Approach for Angle Measuring Precision Improvement in Monopulse Radar System[J]．Radar Science and Tecnology, 2009, 7(5): 380-381.

[10] Trees H.L. V, Tang Jun, etal. Optimum Array Processing[M]. Bei jing: Tsinghua University Press, 2008, 201-208.
