Bearing Capacity Predicting Method on Mortar-Rock Interface of Compression Type Rock Anchor

Abstract:

To predict bearing capacity on mortar-rock interface of compression type rock anchor, the failure model of fixed anchor length is established. The maximal shear stresses on the interface in front of the bearing plate are determined based on tests. The relation of maximal shear stress and fixed anchor length is assumed. Double exponential function curves are adopted to simulate the ultimate state of the fixed anchor length. Two parameters are introduced to adjust the curve shape. According to the results of the field test, the values range of the parameters in soft rock is determined. After comparing ultimate bearing capacity measured in test with predicting value, it is shown that the empirical formula can calculate the bearing capacity of fixed anchor length reasonably. Compression type rock anchors have more capacity than ordinary tension type anchors and the capacity is convergent gradually with fixed anchor length increase.

• Periodical: Applied Mechanics and Materials (Volumes 357-360)
• Pages: 880-883
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.357-360.880
• Online since: August 2013
• Authors: Li Lu*, Shu Guang Wu
• Keywords: Bearing Capacity, Compressing Type Rock Anchor, Fixed Anchor Length, Predicting Method

References

[1] Si-Ping ZHANG, Qing HOU. [J]Journal of Chongqing Jianzhu University , Vol. 26(2) (2004). P. 41-47. (In Chinese).

[2] Li LU, Yongxin ZHANG. [J]Rock and soil Mechanics, Vol. 31(8) (2010). P. 2435-2440. (In Chinese).

[3] Li LU, Yongxing ZHANG. [J]Journal of Civil, Architectural & Environmental Engineering, Vol. 33(5) (2011). P. 69-74. (In Chinese).

[4] Chun-an You. [J]Chinese Journal of Geotechnical Engineering, Vol. 26（6）(2004).P. 828-831. (In Chinese).
