Research and Design of Simple Numerical Control System of Valve Block Processing

Abstract:

During the design and manufacture of hydraulic system, valve block of processing is time-consuming and labor-intensive, and its easy to make a mistake. In this paper, a simple numerical control system based on PLC control to solve the practical engineering problem is studied. An automatic positioning based on parameters of holes which are drawn by AutoCAD and an automatic machining of holes can be realized by the control system. Its also discussed that the method and process of the design of software and hardware.
