Research on the Integrated Control System of a Small Marine Condenser

Abstract:

In order to effectively control the main parameters of the condenser, the lumped parameter mathematic model of a small marine condenser is presented according to its structure and working principle. The integrated control system of the condenser is designed. Matlab/Simulink software is used for the simulation of the control system. Different operating conditions of the condenser are calculated. Result shows that the integrated control system of the condenser could effectively keep such controlled parameters as vacuum, condensate subcooling degree and water level at the set value. It has guiding significance for control system design of the marine condenser.

• Periodical: Applied Mechanics and Materials (Volume 364)
• Pages: 319-323
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.364.319
• Online since: August 2013
• Authors: Yong Sheng Zhang, Xue Chuang Peng, Rui Ma, Wei Ming Fang
• Keywords: Condenser, Control, Level, Subcooling Degree, Vacuum

References

[1] Sun Jian-hua and Qiu Zhi-qiang: Ship Science and Technology, Vol. 6 (1999), pp.15-19.

[2] Wan Hua-qing, Yao Yong-tao, Pan Yan and Sun Jian-hua: Ship Science and Technology, Vol. 30(2008), pp.80-83, 110.

[3] Liu Wei-ting, Zhang Bing and Zhu Zhi-yu: Journal of University of Electronic Science and Technology of China, Vol. 35(2006), pp.356-358.

[4] Zhang Yong-sheng and Ma Yun-yi: Ship Science and Technology, Vol. 33(2011), pp.62-64, 89.

[5] Yu Tian-xing, Shan Jun and Wang Peng: Control Engineering of China, Vol. 13(2006), pp.89-92.
