Research on Automatic Exchange of Mill Heads of Movable Beam Type Machining Center

Abstract:

After analysis of the mill head magazine, the attachment to the movable beam type machining center XH2125/H-800, which is of SIEMENS840D numerical control system, is developed in this paper, the software contains automatic exchange of mill head function controls. This software compromises the functions of the user variables and the high-level programming language, and is based on the data exchange and data comparison between CNC and PLC. All mill heads locates in the magazine that can distinguish, search and exchange automatically, and this system can display the suggestive information or failure warning safeguard in time on the operation screen to make it easy for user to operate.

• Periodical: Applied Mechanics and Materials (Volume 364)
• Pages: 324-328
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.364.324
• Online since: August 2013
• Authors: Gen Ji Cao, Ya Qing Kong, Jiang Liu, Jun Fang Ni
• Keywords: Automatic Exchange, Mill Head, Mill Head Magazine, PLC Program

References

[1] User documentation. SINUMERK840D/810, List of System Variables, Parameter Manual, 11[Z]. 2006 Edition.

[2] User documentation. SINUMERIK840D/810D, Job Planning, Programming Manual, 11[Z]. 2006 Editions.

[3] Manufacturer/Service documentation. SINUMERIK840D/810D (CCU2)/FM-NC, Special Function (Part3) Description of Function Manual, 08[Z]. 2006 Edition.

[4] Manufacturer/Service documentation. SINUMERIK840D/810D, Lists, Parameter Manual, 11[Z]. 2006 Editions.

[5] Zhao Jie, Hou Yong-Liang. X62W milling machine numerical control reconstruction the choice of stepping motor. Development and Innovation of machinery and electrical products. 2010, 23 (3): 184-185.

[6] Zhang Yi, Lou Jianyong. The CNC transformation of X52 vertical milling machine. 2009, 38 (02): 100-102.
