Design of an Active-Gm-RC Reconfigurable Filter for the Multi-Mode Receiver

Abstract:

Based on TSMC 0.18m RF CMOS process a reconfigurable low-pass filter (LPF) is presented in this paper. The LPF adopts active-Gm-RC structure. By manually adjusting the capacitor arrays, the LPF can switch working mode and correct frequency offset caused by process deviation. The pre-layout simulation shows that with 1.8V power supply, the bandwidth ranges from 1.4MHz to 9.8MHz with a step of 1.4MHz. The out of band attenuation is about-80dB/10 octave and the power consumption is 0.43mW .

You might also be interested in these eBooks

Mechanical Automation and Materials Engineering

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volume 364)

Pages:

458-462

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.364.458

Citation:

Cite this paper

Online since:

August 2013

Authors:

Lei Qian, Xiang Ning Fan

Keywords:

Active-Gm-RC Structure, Capacitor Arrays, Folded Cascode Transconductance Operational Amplifier, Low-Pass Filter, Reconfigurable

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Stefano D'Amico, and Andrea Baschirotto. Active-Gm-RC Continuous-Time biquadraticratic Cells[J]. Analog Integrated Circuits and Signal Processing, 45, 281–294, (2005).

DOI: 10.1007/s10470-005-4956-9

Google Scholar

[2] Stefano D'Amico, Vito Giannini and Andrea Baschirotto. An Algorithm for the Automatic Design and the Power Optimisation of Active-Gm-RC Continuous-Time biquadraticratic Cells[C]. Regular Session G : High Voltage Techniques & Continuous Time Filtering.

DOI: 10.1109/newcas.2004.1359099

Google Scholar

[3] Stefano D'Amico, Vito Giannini, and Andrea Baschirotto. A 4th-Order Active-Gm-RC Reconﬁgurable (UMTS/WLAN) Filter[J],. IEEE Journal of Solid-State Circuits, Vol. 41, No. 7, July (2006).

DOI: 10.1109/jssc.2006.873676

Google Scholar

[4] Chi Baoyong. Analog Integrated Circuits and Systems[M]. Beijing: Tsinghua University Press, (2009).

Google Scholar

[5] He Lenian and Wang Yi. Analog Integrated Circuits Design and Simulation[M]. Science Press, (2008).

Google Scholar
