Modeling and Simulation of Thermostatic Mixing Valve

Abstract:

It researched a new type of intelligent thermostatic mixing valve which could keep the temperature and flux of the valve outlet water constant through the adaptive controller. It firstly established the mathematical model about angle - flux and angle - temperature of the valve. And then it based on the kε turbulence model and applied Fluent software to numerical simulation of the valve about the flow field. Finally, it compared the simulation results with the calculated value. The results show that they are basically consistent, prove the correctness of the theoretical research, and can be used to improve designing of the thermostatic valve.

• Periodical: Applied Mechanics and Materials (Volumes 365-366)
• Pages: 370-374
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.365-366.370
• Online since: August 2013
• Authors: Hai Chu Chen, Fang Yi Wu, Ping Zhang, Gen Liang Xiong, Yin Fa Zhu
• Keywords: FLUENT Simulation, Mathematical Modeling, Thermostatic Valve

References

[1] L.S. Luo, C.Y. Wang, H. Yuan, et, al. A New Kind of Three-way Thermostatic Valve. Chinese Hydraulics & Pneumatics, (2008) no. 3, pp.78-80.

[2] C.G. Cai, T. Jin. Yu. Development and Utilization of Thermostatic Valve for SWH. Solar Energy, Vol. 43 (2009) no. 1, pp.36-37.

[3] H.C. Wu, et, al. Development Performance Analysis and Test of the Thermovalve in Energy-saving Cooling System. Chinese Hydraulics & Pneumatics, (2004) no. 11, pp.19-21.

[4] H. Matsui, M. Enoki, T. Kato, et, al. Application of Shape Memory Alloy to Thermostatic Mixing Valve. Journal de Physique. IV, (1995) no. 5(8 part2), pp.1253-1258.

DOI: 10.1051/jp4/1995581253

[5] Ohkata I，Tamur H. R-phase transformation in the Ti-Ni shape memory alloy and its application. Materials Research Society Symposium – Proceedings, (1997) no. 459, pp.345-355.

[6] S.X. Li, Q.H. Ba, Y. Sui, et, al. Test and Research on the Wax-formula Thermostatic Valve in Cooling System of Locomotive Engine. Fluid Machinery, Vol. 34 (2006) no. 9, pp.4-7.

[7] S.Q. He, X. Liu, X.Y. An，et, al. Study on Law of Preparing Paraffin Used in Thermostatic Valve Based on DTA Analysis. Fluid Machinery, Vol. 36 (2008) no. 10, pp.8-10.

[8] G.Z. Wang, L.H. Ji, S.Z. Wen, et, al. Thermal Expansion Formula Micro-actuator Actuated by Induction Heating. Chinese Journal of Mechanical Engineering, Vol. 39 (2003) no. 2, pp.79-83.

[9] H.C. Chen, X.Y. Wang, R.H. Zhang, et, al. Design and modeling of precise flux valve driven by piezoelectric ceramics. Journal of Zhejiang University (engineering edition), vol. 42 (2008) no. 11, p.1936-(1939).
