Research and Implementation of Single Switch Voltage Clamped Hybrid DC-DC Converter

Abstract:

Recently, micro-inverter has received great attention due to its excellent performance under local shade condition. However, this kind of inverter needs large DC-DC voltage gain to implement grid-connected power generation for single photovoltaic module. This paper presented a new single switch high voltage gain DC-DC converter, which is consist of a double output voltage Boost converter and a flyback converter. The outputs of both converters are connected in series to supply power for the load, so the proposed converter has high voltage gain. Moreover, the input circuit is shared by the boost converter and the flyback converter in this new converter, which facilitates the converter structure and improves the converter efficiency by recycling the transformer leakage energy. The double output voltage boost converter can reduce the turn ratio of the flyback transformer and it can decrease the leakage inductance of transformer and diode voltage stress. In addition, the clamp capacitor can limit the power device voltage stress and simplify the circuit design. The paper analysis the operation process of presented converter and gives the detailed deduction of relevant formula to guide the converter design. Experimental results verify the presented converter.

• Periodical: Applied Mechanics and Materials (Volume 367)
• Pages: 181-187
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.367.181
• Online since: August 2013
• Authors: Zhang Chao, Zhou Qiang, Xu Lei, He Xiang Ning
• Keywords: Double Output Voltage Boost Converter, Flyback Converter, High Voltage Gain, Voltage Clamped

References

[1] Shams El-Dein, M.Z., M. Kazerani and M.M.A. Salama, Optimal photovoltaic array reconfiguration to reduce partial shading losses. IEEE Transactions on Sustainable Energy, 2013. 4(1): pp.145-153.

DOI: 10.1109/tste.2012.2208128

[2] Lavado Villa, L.F., et al., A power electronics equalizer application for partially shaded photovoltaic modules. IEEE Transactions on Industrial Electronics, 2013. 60(3): pp.1179-1190.

DOI: 10.1109/tie.2012.2201431

[3] Shams El-Dein, M.Z., M. Kazerani and M.M.A. Salama, Optimal photovoltaic array reconfiguration to reduce partial shading losses. IEEE Transactions on Sustainable Energy, 2013. 4(1): pp.145-153.

DOI: 10.1109/tste.2012.2208128

[4] Li, W., et al., Interleaved high step-up ZVT converter with built-in transformer voltage doubler cell for distributed PV generation system. IEEE Transactions on Power Electronics, 2013. 28(1): pp.300-313.

DOI: 10.1109/tpel.2012.2199771

[5] Deng, Y., et al., Single-switch high step-up converters with built-in transformer voltage multiplier cell. IEEE Transactions on Power Electronics, 2012. 27(8): pp.3557-3567.

DOI: 10.1109/tpel.2012.2183620

[6] Hu, H., et al. Power decoupling techniques for micro-inverters in PV systems-A review. in 2010 2nd IEEE Energy Conversion Congress and Exposition, ECCE 2010, September 12, 2010 - September 16, 2010. 2010. Atlanta, GA, United states: IEEE Computer Society.

DOI: 10.1109/ecce.2010.5618285

[7] Fang, Y., X. Ma and Y. Xing. Study on PV micro-inverter with coupled inductors and double boost topology. in 2012 7th IEEE Conference on Industrial Electronics and Applications, ICIEA 2012, July 18, 2012 - July 20, 2012. 2012. Singapore, Singapore: IEEE Computer Society.

DOI: 10.1109/iciea.2012.6361068

[8] Fang, Y. and X. Ma, A novel PV microinverter with coupled inductors and double-boost topology. IEEE Transactions on Power Electronics, 2010. 25(12): pp.3139-3147.

DOI: 10.1109/tpel.2010.2087417

[9] Tseng, S.Y., et al. Interleaved coupled-inductor boost converter with boost type snubber for PV system. in 2009 IEEE Energy Conversion Congress and Exposition, ECCE 2009, September 20, 2009 - September 24, 2009. 2009. San Jose, CA, United states: IEEE Computer Society.

DOI: 10.1109/ecce.2009.5316192

[10] Ji, Y., et al. A phase lagging compensation for output current of DCM flyback based PV micro-inverters. in 2012 IEEE 7th International Power Electronics and Motion Control Conference - ECCE Asia, IPEMC 2012, June 2, 2012 - June 5, 2012. 2012. Harbin, China: IEEE Computer Society.

DOI: 10.1109/ipemc.2012.6259019

[11] Liang, T.J. and K.C. Tseng, Analysis of integrated boost-flyback step-up converter. IEE Proceedings: Electric Power Applications, 2005. 152(2): pp.217-225.

DOI: 10.1049/ip-epa:20045003
