Simulation and Analysis for Spin Angle Track of the Ball Machined by Dual Rotation Plates Lapping Method

Abstract:

Spin angle is an important target of expressing ball rotation in the lapping process. Whether lapping track can uniformly cover the ball surface or not is directly determined by the variation of the angle. The simulation of spin angle track of the ball based on ADAMS (Automatic Dynamic Analysis of Mechanical Systems) with Dual Rotation Plates Lapping Method by applying virtual prototype technology and using ADAMS is given by the article. The track based on ADAMS is similar with the track of using mathematical theory on the whole. The simulation results show that DRP lapping method owns better lapping uniformity and it is easy to apply to science for the simplicity of structure and control. The spherical lapping uniformity will be further studied with ADAMS in a convenient way.

• Periodical: Applied Mechanics and Materials (Volumes 37-38)
• Pages: 1148-1152
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.37-38.1148
• Online since: November 2010
• Authors: Dun Liu, Qian Fa Deng, Bing Hai Lv, Wei Feng Yao, Ju Long Yuan
• Keywords: Adam, Dual Rotated Plates (DRP), Sphericity, Spin Angle

References

[1] Rascher: R: Foreign Bearing, (1992) No. 3, pp.38-42.

[2] Y. Guo, J.Z. Sun and Y.S. Lv: Shenyang Ligong University, Vol. 26 (2007) No. 3, pp.38-42. (In Chinese).

[3] R.T. Lee, Y.C. Hwang and Y.C. Chiou: International Journal of Machine Tools & Manufacture, Vol. 46 (2006), pp.1146-1156.

[4] Z.Z. Zhou, J.L. Yuan, B.H. Lv and J.J. Zheng: Advanced Materials Research, Vol. 53-54 (2008), pp.147-154.

[5] B.H. Lv: Research on Ceramic Ball Lapping and Sphere-Shaping Mechanism with Rotated Dual-Plates Machine (Ph. D, Harbin Institute of Technology, China 2007), pp.1-28.

[6] G.Z. Li: Detailed Explanation and Examples of the ADAMS-entry (National Defense Industry, China 2006).
