The Calculation Method of Accurate Shaping Curve of Inside Right-Angle Step in Cross Wedge Rolling

Abstract:

Deep study on Inside Right-angle Step (IRS) forming process was conducted to improve the precision of its (IRS) forming. According to its actual forming process, the zone, or the undeformed zone, was looked as semi-spiral declined cone and excluded the contact zone. A new algorithm was developed for calculating the size of the undeformed zone. More simple mathematical models and expressions weredeveloped for solving the shaping curve. The model was verified in terms of its simplicity and correctness based on the numerical simulation.

• Periodical: Applied Mechanics and Materials (Volumes 37-38)
• Pages: 1416-1420
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.37-38.1416
• Online since: November 2010
• Authors: Ran Zhao, Kang Sheng Zhang, Zheng Huan Hu
• Keywords: Contact Zone Size, Cross Wedge Rolling (CWR), Inside Right-Angle Step, Shaping Curve

References

[1] Z.H. Hu, K.S. Zhang, B.Y. Wang, X.D. Shu and C.P. Yang: Technology and Simulation that Cross Wedge Rolling Forming Parts (Publishing House of Metallurgical Industry, Beijing 2004). (In Chinese).

[2] H.P. Du, K.S. Zhang and Z.H. Hu: China Mechanical Engineering, Vol. 16 (2005) No. 12, pp.1100-1103. (In Chinese).

[3] H.P. Du, K.S. Zhang, H.L. Shi and Z.H. Hu: Journal of University of Science and Technology Beijing, Vol. 26 (2004) No. 6, pp.658-661. (In Chinese).

[4] H.P. Du: Study of the Key Subjects on The Accurate Shaping of Workpiece for Cross Wedge Rolling (Ph.D., University of Science & Technology Beijing, China 2006), pp.22-31. (In Chinese).

[5] C.X. Liao: The Study of Accurate Shaping of Inside-Right-Angle Step of Cross Wedge Rolling (MS., University of Science & Technology Beijing, China 2009), pp.12-35. (In Chinese).
