The Kinematic Analysis of Heart-Shaped Gear Continuously Variable Transmission

Abstract:

Based on the research of non-circular gear Continuously Variable Transmission (CVT), firstly the working principle of the heart-shaped gear is introduced, and then the kinematic characteristics are analyzed, lastly the feature of the heart-shaped gear CVT is obtained.

• Periodical: Applied Mechanics and Materials (Volumes 37-38)
• Pages: 1489-1492
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.37-38.1489
• Online since: November 2010
• Authors: Chuan Qiong Sun, Guo Xing Sun, Ai Hua Ren, Yong De Liu
• Keywords: Continuously Variable Transmission, Heart-Shaped Gear, Impulsion Rate, Kinematic Characteristic

References

[1] F.S. Li: Non-circular Gears and Special Gear Design (Machinery Industry Press, P.R.C. 1983) (in Chinese).

[2] X.T. Wu and G.H. Wang: The Non-circular Gear and the Variable Ratio Transmission (Machinery Industry Press, P.R.C. 1997) (in Chinese).

[3] X.Y. Meng and Q. Jiang: Configuration and Application of Mechanism(Machinery Industry Press, P.R. C 2004) (in Chinese).

[4] J.H. Kerr: U.S. Patent. 3919895(1975).

[5] D. Dooner, H.D. Yoon and A. Seireg: Drive System Technique, Vol. 14(2000) No. 1, pp.38-47(in Chinese).

[6] Z.H. Zhou: P.R.C. Patent 94102177. 7(1994) (in Chinese).

[7] Z.H. Zhou: Journal of Mechanical Transmission, Vol. 25(2001) No. 2, pp.31-33(in Chinese).

[8] G.X. Sun and Y.D. Liu: Journal of Hubei Automotive Industries Institute， Vol. 19(2005) No. 1, pp.9-12(in Chinese).
