Experimental Design Methodology in Ball End Milling of C45 Material by Using Tool Tilt Angle - Analysis and Estimation of Surface Roughness Variation

Abstract:

Due to the expansion of milling process with ball end mill in various branches of industry it became necessary for this process to be optimized. For this purpose it is necessary to identify the parameters that influence the process and establish their value for witch the results obtained to be the maximum in terms of qualitative and quantitative. Roughness of the surface machined can be considered as an important element that reflects the degree of successful optimization of this process. In order to solve the problems relating to the analysis and estimation of the surface roughness variation in ball end milling of C45 material with tool tilt angle, in this paper it was designed an experimental methodology followed by analysis of experimental data and estimation of surface roughness variation. The experimental research methodology presented in this paper can be extrapolated and used in a large number of processes.

• Periodical: Applied Mechanics and Materials (Volume 371)
• Pages: 48-53
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.371.48
• Online since: August 2013
• Authors: Ioan Pasca, Mircea Lobonțiu, Róbert Čep, Mihai Banica
• Keywords: Analysis, Ball-Nose End Mill, Milling, Roughness, Surface, Tilt

References

[1] M. Yamada, T. Kondo, F. Tanaka and T. Kishinami, Tilted tool axis machining on 5-axis machine tools, International Journal of Automation Technology. Vol. 1, No. 2 (2007) 120-127.

DOI: 10.20965/ijat.2007.p0120

[2] E. Ozturk, L.T. Tunc, and E. Budak, Investigation of lead and tilt angle effects in 5-axis ball-end milling processes, International Journal of Machine Tools and Manufacture. 49, 14 (2009) 1053-1062.

DOI: 10.1016/j.ijmachtools.2009.07.013

[3] M. Sadilek, R. Cep, I. Budak, and M. Sokovic, Aspects of using tool axis inclination angle, Journal of Mechanical Engineering. 57 (2011) 681-688.

DOI: 10.5545/sv-jme.2010.205

[4] M. Sadilek, and R. Cep, Progressive strategy of milling by means of tool axis inclination angle, World Academy of Science, Engineering and Technology. 29 (2009) 655-659.

[5] A. Daymi, M. Boujelbene, J. M. Linares, E. Bayraktar and A. B. Amara, Influence of workpiece inclination angle on the surface roughness in ball end milling of the titanium alloy Ti-6Al-4V, Journal of Achievements in Materials and Manufacturing Engineerin., Vol. 35, No. 1 (2009).

DOI: 10.1179/026708310x12738371692932

[6] M. Alauddin, M. A. Baradie, and M. Hashmi, Prediction of tool life in end milling by response surface methodology, Journal of Materials Processing and Technology 71 (1997) 456-465.

DOI: 10.1016/s0924-0136(97)00111-8

[7] M. Boujelbene, A. Moisan, W. Bouzid and S. Torbaty, Variation cutting speed on the five axis milling, Journal of Achievements in Materials and Manufacturing Engineering. Vol. 21, No. 2 (2007) 7-14.

[8] J. Peterka, The new approach of calculating the arithmetic mean deviation of surface roughness of machined surfaces during ball end milling, International Journal of Engineering and Technology. Vol. 9, No. 2 (2004) 28-32.
