On-Line Verification of Relay Protection Setting Based on Transmission Contribution Degree

Abstract:

In this paper, a new method that is based on the transmission contribution degree is proposed, which can effictively imprve on-line verification of relay protection setting.Actually, all protection devices of a line are treated as a whole in this method. Furthermore, the network maximum flow and complex network theory are both applied in this method, which is on the view of the structural point of the grid. The importance index of protection device in a line is determined by the transmission contribution degree. As a result, on-line verification of relay protection setting is according to the descending order of the indexes. IEEE 39-bus system is used to simulate, on the whole, the simulation and analysis of the calculation results to verify the reasonableness and correctness of the method.

• Periodical: Applied Mechanics and Materials (Volumes 373-375)
• Pages: 1497-1502
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.373-375.1497
• Online since: August 2013
• Authors: Zong Jiang Mu, Yan Xu, Xing Dong Qiu, Jin Jie Wang
• Keywords: Degree of Importance, Distribution Factor of Power Transmission, On-Line Verification, Protection Device of Branch Line, Transmission Contribution Degree

References

[1] Genghui Zeng, Yinhong Li and Xianzhong Duan: Relay Vol. 30(1) (2002), pp.22-24.

[2] Yongli Zhu, Shaoqun Song and Guoqiang Zhu: Automation of Electric Power Systems Vol. 29(6) (2005), pp.87-92.

[3] Ying Lu, Hongbin Sun and Boming Zhang: Automation of Electric Power Systems Vol. 30(4) (2006), pp.1-5.

[4] Haixiang Zhang, Feipeng Lu and Xiaojun Liao: Automation of Electric Power Systems Vol. 36(19) (2012), pp.1-6.

[5] S. Tamronglak, A.G. Phadke and S.H. Horowitz: Proceedings of the IEEE/PES Winter Meeting(1995).

[6] Wenyun Ju and Yinhong Li: Automation of Electric Power Systems Vol. 36(9) (2012), pp.6-12.
