Numerical Simulation of Internal Flow Field on Diesel Centrifugal Gas-Oil Separator Based on CFD

Abstract:

Aiming at the low efficiency problem of the traditional gas-oil separator, this paper put forward a centrifugal gas-oil separator. In order to identify out the interior fluid field character of centrifugal gas-oil separator, RANS equation, RNG k-ε model and discrete phase model was applied to simulate the interior fluid field character and separation efficiency of centrifugal gas-oil separator. The simulation results showed that the flow field in the disc clearance was mainly laminar flow, and the flow field at the import and export of the disc was turbulence. Meanwhile, the velocity and pressure of the interior fluid field were equably distributed, the velocity and pressure in the disc clearance fluctuate in a tight range along vertical direction, and decrease along horizontal direction, and the particles in the disc clearance were distributed uniformly. The separation efficiency was 96.6% and the results met the design requirements.

• Periodical: Applied Mechanics and Materials (Volumes 373-375)
• Pages: 409-412
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.373-375.409
• Online since: August 2013
• Authors: Zhi Guo Zhao, Wen Ming Yu
• Keywords: Centrifugal Gas-Oil Separator, Diesel, Flow Field, Separation Efficiency

References

[1] Clark N N, Tatli E, Barnett R, et al. Characterization and abatement of disesl crankcase emissions/SAE 2006-01-3372, (2006).

DOI: 10.4271/2006-01-3372

[2] Zong jun-jie, Ni jimin, Qiu xuejun. Study on Performance of Air/Oil Separator in Crankcase Ventilation System. Chinese Internal Combustion Engine Engineering, 2008, 37(3): 50-53. (In Chinese).

[3] A CAMBIELLA, J M BENITO, C PAZOS, J COCA. Centrifgal Separation Efficiencyin the Treatment of Waste Emulsifled Oils. Trans IChemE, Part A, January 2006, 84(A1): 69–76.

DOI: 10.1205/cherd.05130

[4] Alexander Zink, Manfred Piesche. Numerical and Experimental Investigations of a Disc Stack Centrifuge Used as an Oil Mist Separator for Automotive Applications. SAE, 2004-01-0638, (2004).

DOI: 10.4271/2004-01-0638

[5] R. M. Pagnozzi, D.C. Pereira, P. Bastias, L. Spielmann, 2007, Methodology Applied on the Validation of Air/Oil Separation Systems Integrated to the Crankcase Ventilation Valve, SAE technical papers series, 2007-01-27579, (2007).

DOI: 10.4271/2007-01-2757

[6] S. Tekam, M. Demoulin, V. Daru, 2004, Prediction of the Efficiency of an Automotive Oil Separator: Comparison of Numerical Simulations with Experiments, SAE technical papers series, 2004-01-3019, (2004).

DOI: 10.4271/2004-01-3019
