Study on Numerical Simulation Method of Aerodynamic Performance of High-Speed Train on Bridge

Abstract:

The dynamic mesh method that could simulate the actual moving of train was used to calculate the aerodynamic coefficients of train on bridge with wind barriers of various heights, and the static pressure distributions around the train body and velocity magnitude distributions were analyzed, the results computed by dynamic mesh method were compared with that computed by traditional static mesh method. The results show that the aerodynamic coefficients of train and flow field characteristics computed by the two methods agree well under the configuration without wind barriers. However, there is considerable difference between the results computed by the two methods with the installation of wind barriers. It is found that the dynamic mesh method is more reasonable to simulate the aerodynamic coefficients of train with wind barriers by analysis of the contour of static pressure distributions and velocity magnitude distributions. The wind barriers effectively decrease the positive pressure on windward train body and negative pressure on train roof, mainly reduce the side force coefficient, lift force coefficient, rolling moment coefficient. Therefore, the aerodynamic performance of train on bridge under crosswind is improved.

• Periodical: Applied Mechanics and Materials (Volume 376)
• Pages: 312-316
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.376.312
• Online since: August 2013
• Authors: Chao Qun Xiang, Wen Hua Guo, Jia Wen Zhang
• Keywords: Aerodynamic Performance, Dynamic Mesh Method, High-Speed Train, Wind Barriers

References

[1] X. T Dong. Numerical simulation study on influence of wind barriers on the wind environment around bridge deck. Hangzhou: Zhejiang University, (2007).

[2] T Chen. The study on the impact of the setting of high-speed railway bridge's wind barrier on the train and main beam's aerodynamic performance. Changsha: Central South University, (2011).

[3] J. Bettle, A.G.L. Holloway, J.E.S. Venart. A computational study of the aerodynamic forces acting on a tractor-trailer vehicle on a bridge in cross-wind. Journal of wind engineering and industrial aerodynamics, 2003, 91: 573-592.

DOI: 10.1016/s0167-6105(02)00461-0

[4] C.J. Baker. The simulation of unsteady aerodynamic cross wind forces on trains. Journal of wind engineering and industrial aerodynamics, 2010, 98: 88-99.

DOI: 10.1016/j.jweia.2009.09.006

[5] H Kozmar, L Procino, A Borsani, et al. Sheltering efficiency of wind barriers on bridges. Journal of wind engineering and industrial aerodynamics, 2012, 107-108: 274-284.

DOI: 10.1016/j.jweia.2012.04.027

[6] R. B SONG. The numerical study of aerodynamic characteristics of each other when high-speed train move on bridge. Changsha: Central South University, (2011).

[7] M Bocciolone, F Cheli, R Corradi, et al. Crosswind action on rail vehicles: Wind tunnel experimental analyses. Journal of wind engineering and industrial aerodynamics, 2008, 96: 584-610.

DOI: 10.1016/j.jweia.2008.02.030

[8] Y TANG. The Bridge-Windbreak Influence on the Operational Safety of Vehicle under Crosswind. Chengdu: Southwest Jiaotong University, (2010).

[9] J. P ZHENG. Study on the Behaviors of Bridge Windbreak of NANJIANG Railway. Chengdu: Southwest Jiaotong University, (2008).

[10] W. Khier, M. Breuer, F. Durst. Flow structure around trains under side wind conditions: a numerical study. Computers & Fluids, 2000, 29, 179-195.

DOI: 10.1016/s0045-7930(99)00008-0

[11] H. K Versteeg, W Malalasekera. An introduction to computational fluid dynamics. London: Longman Group Limited, 1995: 67-75.
