Modeling Impulse Wire Feed Welding in Controlled Gas Shielding

Abstract:

At present application of a shielding gas (Ar+CO₂) is one of the methods to improve the efficiency of impulse wire feed welding. For further investigation of the considered welding method information processing technologies and the software required are to be applied. Special software “Modeling processes of controlled transfer of the electrode metal drop” is developed, and provides calculation of main technological welding parameters on the basis of adapted mathematical models and algorithms to compute a weld form, changes in heat zones and cooling speed of welded joint zones.

• Periodical: Applied Mechanics and Materials (Volume 379)
• Pages: 183-187
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.379.183
• Online since: August 2013
• Authors: N.V. Pavlov, A.V. Kryukov, E.A. Zernin, V.A. Polischuk
• Keywords: Impulse Wire Feed, Modeling, Special Software, Welding

References

[1] V.T. Fed'ko, O.G. Brunov, P.D. Sokolov, Impulse wire feed welding as a special case of pulsed arc welding, Welding production, 7 (2006) 6-8.

DOI: 10.1533/wint.2006.3730

[2] N.V. Pavlov, A.V. Kryukov, E.A. Zernin, Temperature field distribution in impulse wire feed welding in a gas mixture, Welding production, 1 (2011) 35-36.

DOI: 10.1080/09507116.2011.606167

[3] Y.F. Yazikov, I.V. Alexina, Advantages of welding in shielding gas mixtures, Welding production, 9 (2008) 29-30.

[4] M.V. Karasev, D.N. Rabotinsky, S.V. Golovin, A.P. Ladyzhansky, G.V. Pavlenko, R. Rozert, Stein Drahtug, A.V. Zinchenko, The influence of mechanized welding in gas mixtures on service properties of a surfaced metal, Welder in Russia 6 (2007).

[5] N.V. Pavlov, A.V. Kryukov, E.A. Zernin, Impulse wire feed welding in a gas mixture, Welding production 4 (2010) 27-28.

DOI: 10.4028/www.scientific.net/amm.379.183

[6] V.V. Frolov, Theory of welding processes: a textbook for universities on specialty Welding equipment and technology, Vysshaya shkola, Moscow, (1988).

[7] O.G. Brunov, Impulse wire feed mechanized welding in active gases: a scientific paper, Tomsk Polytechnic University Press (2007) 137.

[8] Y.N. Saraev, A.A. Demyanchenko, D.A. Chinakhov, A.V. Kryukov, N.V. Pavlov, The study of kinetics of melting and transfer of electrode metal in consumable electrode arc welding in shielding gases, Proceedings of the second International scientific and practical conference with scientific school for young scientists Innovative technologies in mechanical engineering and economics: collected works, Tomsk (2011).

DOI: 10.1080/09507116.2017.1343977

[9] S.A. Solodsky, Development of an automated system for impulse wire feed welding in CO2 with welding current modulation, South Ural State University Press, Chelyabinsk, (2010).

[10] B.M. Berezovsky, Mathematical models of arc welding: Volume 1: Mathematical modeling and information technologies, models of the weld pool and weld formation, South Ural State University Press, Chelyabinsk, (2002).

[11] N.N. Rykalin, Calculations of thermal processes in welding, Moscow, (1951).

[12] I.F. Korinets, Zsi Chzhen Chun, Determined and statistical model of a weld shape in arc welding, Automated welding, 10 (2001). 44-47.

[13] .F. Korinets, Zsi Chzhen Chun, . The influence of a gap on butt weld dimensions when consumable electrode arc welding in Ar + 25% CO2, Automated welding, 8 (2002). 16-19.

[14] N.V. Pavlov, A.V. Kryukov, E.G. Domnina, E.A. Zernin, Certificate of state registration of the software Modeling processes of controlled transfer of the electrode metal drop, 2011616056, (2012).
