Enlarge the Field of View of Nano CT in Synchrotron Radiation

Abstract:

nanoCT with synchrotron radiation has a high spatial resolution up to nanoscale which provides an approach to the 3D inter-structure of sample of tiny size in the research of biology, materials and so on. However, due to the high resolution it provide, the field of view is limited to only about 15~60μm. In order to improve the scale of field of view, we discussed a new scan mode called half-scan which is using the symmetry of parallel-beam x-ray and newly applied in the synchrotron radiation imaging field. In this paper, we deduced the data processing method which is consisted of data preprocessing and filter back projection (FBP) algorithm. Numerical simulation and analysis demonstrate that the field of view can be enlarged up to 100% with this method.

• Periodical: Applied Mechanics and Materials (Volumes 380-384)
• Pages: 1808-1811
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.380-384.1808
• Online since: August 2013
• Authors: Ren Bo Tan, Jian Fu, Li Yuan Chen
• Keywords: FBP, FOV, Half-Scan Mode, High Resolution, Nano CT, Synchrotron Radiation

References

[1] Meyer-Ilse, W., Hamamoto, D., Nair, A., Lelièvre, S. A., Denbeaux, G., Johnson, L., Pearson, A. L., Yager, D., Legros, M. A. and Larabell, C. A., High resolution protein localization using soft X-ray microscopy,. Journal of Microscopy, 2011, Vol201, p.395.

DOI: 10.1046/j.1365-2818.2001.00845.x

[2] Chen Jie, Liu Longhua, Liu Gang, Tian Yangchao. High resolution X-ray microscopy and its new developments,. Physics, 2007, Vol(08), pp.588-594.

[3] Le Gros M A, McDermott G, Larabell C A. X-ray tomography of whole cells,. Current Opinion in Structural Biology. Vol15, pp.593-600.

DOI: 10.1016/j.sbi.2005.08.008

[4] B. Lai, W. B. Yun, D, Legnini, et al. Hard x-ray phase zone plate fabricated by lithographic techniques,. Appl. Phys. Lett, 1992, Vol61(16), pp.1877-1879.

DOI: 10.1063/1.108400

[5] Fu Jian, Lu Hongnian. Novel ICT scan mode and its FBP reconstruction algorithm,. Journal of Beijing University of Aeronautics and Astronautics, 2003, Vol29 (1), pp.9-12.

[6] Fu Jian, Lu Hongnian. Research of large field of view scan mode for industral CT,. Chinese Journal of Aeronautics, 2003, Vol16(1) , pp.59-64.

DOI: 10.1016/s1000-9361(11)60172-6

[7] Fu Jian, Lu Hongnian. Bias scan mode for fan beam X-ray ICT and its reconstruction algorithm,. Optical Technique, 2003, Vol29(1), pp.115-118.

[8] Herman G T. Image reconstruction from projection: the fundamentals of computed tomography. New York: Academic Press, (1980).

[9] Kak A C, Slaney M. Principles of computerized tomographic imaging. New York: IEEE Press, (1999).

[10] Zhuang Tiange. CT principle and algorithm. Shanghai: Shanghai Jiaotong University Press, (1992).
