Finite Element Analysis of Accessorial Equipments for Carring the Wounded by Airliners Based on MSC.PATRAN

Abstract:

According to the design criteria referred to CCAR-25,the static strengths of accessorial equipments (single stretcher-supporting equipment, double layer stretcher-supporting equipment and nursing-type unit) and the track-mounting mechanism applied to fix the accessorial equipments to the seat tracks of the airliner are analyzed under five loads by using the software MSC.PATRAN. Based on the analysis results, the strengths of the accessorial equipments will be checked, the structures can satisfy the requirements of strength.

• Periodical: Applied Mechanics and Materials (Volume 389)
• Pages: 1065-1068
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.389.1065
• Online since: August 2013
• Authors: Li Tang, Jing Tao Yue, Yin Zhang
• Keywords: Accessorial Equipment, Airliner Carry, Finite Element Analysis (FEA), Wounded

References

[1] General Administration of civil aviation of China. CCAR-25-R3 transport aircraft airworthiness standards. Chin Civil Aviation press: 2001, 25. 561 (b) (3).

[2] General Administration of civil aviation of China. CCAR-25-R3 transport aircraft airworthiness standards. China Civil Aviation press: 2001, 25. 785 (f) (3).

[3] General Administration of civil aviation of China. CCAR-25-R3 transport aircraft airworthiness standards. China Civil Aviation press: 2001, 25. 785 (f).

[4] Xu Hao. Handbook of mechanical design, mechanical industry press, 1999: 3-341.

[5] Xu Hao. Handbook of mechanical design, mechanical industry press, 1999: 3-95.

[6] Xu Hao. Handbook of mechanical design, mechanical industry press, 1999: 2-47.
