Measurement and Visualization of Large Aero-Optics Wavefront Distortion Field in Wind Tunnel Testing

Abstract:

A method of measuring wavefront distortion field is presented in this paper, which gets the OPD through measuring deviation displacement field induced by the beams from center of camera to the mark points crossing the flow field. The experiments of a trans-aerosphere vehicle model in 2 meter supersonic tunnel have demonstrated that the method of this paper can be used to measure the large field of wavefront distortion, and the structures of wavefront distortion generated by oblique shock waves of the vehicles head and wing are correct. This method is simple and provides a new way to measure and observe aero-optics phenomena.

• Periodical: Applied Mechanics and Materials (Volume 389)
• Pages: 1053-1057
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.389.1053
• Online since: August 2013
• Authors: Zheng Yu Zhang, Xu Hui Huang, Jiang Yin, Tao Zhao, Run Zhou
• Keywords: Aero-Optics, Fluid Visualization, Wavefront Distortion, Wind Tunnel Test

References

[1] Stanislav G, Eric J. Aero-Optics of Supersonic Boundary Layers [J]. AIAA, 2011-1325.

[2] Chris P, Mark R, Eric J. The Aero-Optical Environment of a Helicopter in Hover [J]. AIAA , 2011-1328.

[3] R Mark R, Grady C, Eric J J. Aerodynamic Design of an Aircraft-Mounted Pod for Improved Aero-Optic Performance [J]. AIAA, 2010-437.

[4] Zhao Yuxin, Yi Shihe, Tian Lifeng. Aero-optic Distortion and Jitter in Supersonic Mixing Layer [J]. Science China Press: Physics Mechanics Astronomy, Vol. 40(2010), pp.33-46.

[5] Abhishek Bichal, Brian Thurow. Development of a Background Oriented Schlieren Based Wavefront Sensor for Aero-Optics [J]. 40th Fluid Dynamics Conference and Exhibit, (2010).

DOI: 10.2514/6.2010-4842

[6] Feng Sheng. Wave-front Sensing Technique Research [D]. University of Electronic Science and Technology of China (2009).

[7] L. Venkatakrishnan, G.E. Ameier. Density measurements using the Background Oriented Schlieren technique [J]. Experiments in Fluids, Vol. 37(2004), pp.237-247.

DOI: 10.1007/s00348-004-0807-1

[8] V K Kindler, Erik G, Friedrich L. Recent developments in background oriented schlieren methods for rotor blade tip vortex measurements [J]. 13th Int Symp on Applications of Laser Techniques to Fluid Mechanics, Vol. 7 (2006) , pp.26-29.

DOI: 10.1007/s00348-007-0328-9

[9] J.M. Desse, R. Deron. Shadow, Schlieren and Color Interferometry [J]. Optical Diagnostics of Flows, Vol. 10(2009).

[10] Lv Xiaoliang, Temperature measurement based on background oriented schliren[D]. zhejiang University (2011), pp.23-25.

[11] Zhang zhengyu, Huang Shijie, Luo Chuan et al. Nonlinear Distortion Correction of Camera Based on Coplanar Condition Equations [J]. Acta Optica Sinica, Vol. 32(2012), pp.0115002-6.

DOI: 10.3788/aos201232.0115002

[12] Zheng Yu Zhang, Shui Liang Wang. Videogrammetric measurement for model displacement in wind tunnel test [J]. Applied Mechanics and Materials, Vol. 130-134(2011), pp.103-107.

DOI: 10.4028/www.scientific.net/amm.130-134.103

[13] Sun Yan, Zhang Zhengyu, Huang Shijie, et al. Vision measurement for model angle of attack in wind tunnel tests. Acta Aeronautica et Astronautica Sinica , Vol. 34 (2013), pp.1-7.

[14] ZHANG Zhengyu, Sun Zhongxiang, Huang Xuhui. Videogrammetry of the model's attitude in wind tunnel testing. Applied Mechanics and Materials, Vol. 190-191(2012), pp.1273-1277.

DOI: 10.4028/www.scientific.net/amm.190-191.1273
