The Research on Deep and Narrow Groove Grinded by Diamond Wheel

Abstract:

The deep narrow groove of the coupling plate and side with WC-CO coating was grinded by diamond wheel with metal bond and vitrified bond. The side of the deep trench flatness error was less than 0.02 mm, the bottom of the tank around the corner radius was less than 0.3mm. The type of porosity, particle sizes, surface roughness were measured by experiments, the data for the selection of the grinding wheel bond varieties. The experimental results show that grinding wheel with vitrified bond was suitable for parts of small coating porosity, fine particle size, surface roughness, and others were suitable for the grinding wheel with metal binder.

• Periodical: Applied Mechanics and Materials (Volume 389)
• Pages: 281-283
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.389.281
• Online since: August 2013
• Authors: Chun Yang Tang, Long Wu, Zhi Long Li, Hua Feng Lu, Hua Yang, Qing Qing Li, Rong Fa Chen
• Keywords: Diamond Wheel, Grinding, Shape

References

[1] Li Juli, Li Changshi, Guo Jianming Research and Development of Metal Bonded Diamond Grinding Wheel Tool Engineering 2003, 37( 9) : 3~5(in Chinese).

[2] Lin Jindong, Huang Qikui The research of diamond wheel dressing experiment Abrasive and Grinding 1993. 5(77): 20~24(in Chinese).

[3] Katsuo Syoji. Studies on Truing and Dressing of Diamond Wheel(Ⅱ)- Truing Mechanism of Metal Bonded . DiamondWheel with GC Cup-truer Abrasive and Grinding 1993. 3(75): 6~11(in Japanese).

[4] Li Yafei, ZhaoWenxiang, Wang Xibing . Wheel dressed With Cup Wheel Diamond & Abrasives Engineering 2004. 5(143): 37~39(in Chinese).

[5] Brian K. Rhoney, Albert J. shih, Ronald o. scattergood et, al. Wear mechanism of metal bond diamond wheels trued by wire electrical discharge machining. Wear 2002. 4(252): 644~653.

DOI: 10.1016/s0043-1648(02)00019-4

[6] Shuang-Xi Wang, Lin Geng, Xue-Jing Liu et, al. Manufacture of a new kind diamond grinding wheel with Al-based bonding agent. Journal of Materials Processing Technology 2009. 2(209): 1871-1876.

DOI: 10.1016/j.jmatprotec.2008.04.045

[7] Yan wang, Xiao-jun zhou, De-jin Hu. An experimental investigation of dry-electrical discharge assisted truing and dressing of metal bonded diamond wheel. International Journal of machine Tools and Manufacture 2006. 3(46): 333-342.

DOI: 10.1016/j.ijmachtools.2005.05.022

[8] Genyu Chen, Lifang Mei, Bi Zhang et, al. Experiment and numerical simulation study on laser truing and dressing of bronze-bonded dimond wheel. Optics and Lasers in Engineering. 2010, 3(48): 295-304.

DOI: 10.1016/j.optlaseng.2009.11.006
