Design of an ASIC Chip for Spacecraft Data System

Abstract:

ASIC (Application Specific Integrated Circuit) technology is mature and widely used in many fields. It is a trend to integrate some common spacecraft engineering requirements into one chip to take the place of FPGA and some digital chips, which can miniaturize spacecraft avionics and reduce the repeated work for spacecraft engineers. Based on the analysis on small satellites application requirements, the system design of an ASIC chip for spacecraft data system is proposed. Firstly, the chip system architecture is described. Secondly, four key technologies of the ASIC chip design are presented in detail. They are the design of the chip's operating modes, the design of IP cores, the design of reliability, and the design of low power consumption. Generality, adaptability and independent intellectual property make this ASIC different and special from other space chips. Four operating modes are optional: 1553B bus control mode, PCI control mode, ISA control mode, internal CPU control mode. Besides, there are 1553B bus protocol IP cores, CAN bus interface, and abundant peripherals, which can satisfy most of the routine engineering requirements in small satellites. Finally, the chips status and some promising applications are described.

• Periodical: Applied Mechanics and Materials (Volume 390)
• Pages: 611-615
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.390.611
• Online since: August 2013
• Authors: Li Zhou, Jun She An, Qing Wen Fang, Fei Cai
• Keywords: ASIC, MIL-STD-1553B, Onboard Data Handling, Small Satellites, SoC, Spacecraft Data System

References

[1] Robert Caffrey, Michale Cuviello. A standard spacecraft data system on a chip: NASA Goddard Space Flight Center's Essential Services Node (ESN). IEEE Aerospace Conference, 1997(14), p.505.

DOI: 10.1109/aero.1997.574908

[2] Surrey Space Centre. A System-on-a-Chip for small satellite data processing and control (ChipSat, ) . ESA Contract 14894. 2003, 10.

[3] http: /www. esa. int/TEC/Microelectronics.

[4] Zhang Wei-gong, Duan Qing-ya, Wang Jian-feng, etc. The method and study of SOC for managing system of spacecraft bus[J]. Journal of Astronautics, 2005, (03).

[5] C. Dutta, T. Lalitkrushna, K.H. Jeeja, etc. CCSDS complied data handling system for mini satellite. International Conference Communication and Industrial Application (ICCIA), 2011: 1-4.

DOI: 10.1109/iccinda.2011.6146656

[6] Military Specification: Hybrid Microcircuits, General Specification For (S/S BY MIL-PRF-38534C), Military Specifications and Standards, (1992).

[7] Yan Xie, Design and Implementation Of 1553B Remote Terminal IP Core Based on FPGA, [D] Graduate school of Chinese academy of sciences (space science and applied research center), (2011).

[8] Huadong Guo, Ji Wu. Space Science & Technology in China: A Roadmap to 2050. Beijing: Science Publishing Company, 2009. 67-70.
