A Study on Performance Comparison of Integrated Aerodynamic-Ramp-Injector/ Gas-Portfire Flame Holder with Cavity

Abstract:

Experimental study of an integrated aerodynamic-ramp-injector /gas-portfire (aero-ramp/G-P) has been conducted in a hydrogen-fueled scramjet combustor. The aero-ramp injectors consisted of four flush-walled holes, arranged to induce vorticular motion and enhance mixing. For comparison, a recessed cavity with four low downstream-angled circular injector holes was also examined. The combustor models were investigated experimentally using the scramjet direct connected test facility at the Beihang University. The facility can deliver a continuous supersonic flow of Mach number 2 with a total temperature of 1200K. The hot experimental results showed that the combustion efficiency and air specific impulse of aero-ramp/G-P are 85% and 35s while the corresponding values of cavity are 92% and 34s. These results justify the feasibility of aero-ramp/G-P flame holder.

• Periodical: Applied Mechanics and Materials (Volume 390)
• Pages: 8-11
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.390.8
• Online since: August 2013
• Authors: Bao Xi Wei, Qiang Gang, Yan Zhang, Rong Jian Liu, Liang Tian, Xu Xu
• Keywords: Aero-Ramp, Cavity, Gas-Portfire, Performance Comparison, Scramjet

References

[1] Jacobsen L S, Gallimore S D. Improved aerodynamic-rampinjector in supersonic flow [J]. AIAA Journal, 2003 , 19(4): 6632673.

[2] Aristides M. Bonanos. Dual-Mode Combustion Experiments with an Integrated Aeroramp-Injector Plasma-Torch Igniter[J]. Journal of propulsion and power, Vol. 24, No. 2, (2008).

DOI: 10.2514/1.28301

[3] Aristides M. Bonanos. Integrated Aeroramp-Injector Plasma-Torch-Igniter for Methane and Ethylene Fueled Scramjets[R]. AIAA Paper 2006-813, (2006).

DOI: 10.2514/6.2006-813

[4] D. R. Eklund. Numerical Study of a Scramjet Combustor Fueled by an Aerodynamic Ramp Injector in Dual-Mode Combustion[R]. AIAA Paper 2001-A01-16276, (2001).

DOI: 10.2514/6.2001-379

[5] Yan Minglei. Experimental Study on Integrated Aeroramp Injector and Gas-Portfire in a Supersonic Combustor[D]. Beihang University, 2011 (in Chinese).

[6] Cox S.K. Effects of spanwise injector spacing on mixing characteristics of aerodynamic ramp injectors[R]. AIAA 1998-3272.

DOI: 10.2514/6.1998-3272

[7] M. Gruber, J. Donbar and T. Jackson. Performance of an aerodynamic ramp fuel injector in a scramjet combustor[C] AIAA Paper 2000-3708.

DOI: 10.2514/6.2000-3708

[8] Aristides M. B. et al. Scramjet operability range studies of a multifuel integrated aeroramp[R]. AIAA 2005-3425.
