Computer Aided Design and Three-Dimensional Modeling of High-Order Deformed Elliptical Gear

Abstract:

The characteristics of high-order deformed elliptical gear is analyzed. The parameters of high-order deformed elliptical gear are chosen and calculated. The modeling method of high-order deformed elliptical gear is presented. The shape of pitch curve is determined. The position and orientation of gear teeth are clarified. The three-dimensional solid model of high-order deformed elliptical gear is achieved. The method and the result facilitate finite element analysis and numerical control machining simulation of high-order deformed elliptical gear.

• Periodical: Applied Mechanics and Materials (Volume 391)
• Pages: 178-181
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.391.178
• Online since: September 2013
• Authors: Zhi Dong Huang, An Min Hui, Peng Chen, Yu Wang
• Keywords: Computer Aided Design, High-Order Deformed Elliptical Gear, Noncircular Gear, Three-Dimensional Modeling
