New Type of Two Degree of Freedom Motor Three-Dimensional Tooth Layer Field Application and Solution

Abstract:

A new Multi-degree of freedom motor and its establishing of teeth layer parameters have been introduced in the paper, also including application method of database, namely using Quasi-Newton methods to solve the non-linear equations of the new motors magnetic circuit net, formed a refined method for designing and analyzing of motor. The establishment of 3d tooth layer parameters database, is provided for the calculation in the design of the new type motor conveniently.

• Periodical: Applied Mechanics and Materials (Volume 391)
• Pages: 232-236
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.391.232
• Online since: September 2013
• Authors: Wen Huan Yang, Hai Xu Chen, Shuang Xie, Chun Ren Fang
• Keywords: 3D Teeth Layer Parametric Database, Finite Element Method (FEM), Non-Linear Equations, Quasi-Newton Method, Two-Degree of Freedom
